MKDSP 10N/ 2-10,16 BU
MKDSP 10N/ 2-10,16 BU 1710325 PHOENIX CONTACT PCB terminal block base
$0.00USD
3061 in stock
Key Specifications
GTIN:4055626146027
Orderkey:1710325
Packing unit:1
Custom tariff number:85369010
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4055626146027 |
| Orderkey | 1710325 |
| Packing unit | 1 |
| Custom tariff number | 85369010 |
| Pitch (Key Commercial Data) | 10.16 mm |
| (Standards and Regulations) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Range of articles (Dimensions) | MKDSP 10N |
| Nominal current IN (Dimensions) | 76 A |
| Solder pin surface (Dimensions) | |
| Number of positions (Dimensions) | 2 |
| Nominal cross section (Dimensions) | 10 mm² |
| Rated voltage (III/2) (Dimensions) | 1000 V |
| Hole diameter (Key Commercial Data) | 1.5 mm |
| Solder pin [P] (Key Commercial Data) | 5 mm |
| China RoHS (Standards and Regulations) | Environmentally Friendly Use Period = 50 |
| Insulating material group (Dimensions) | I |
| Flammability rating according to UL 94 (General) | V0 |
| Flammability rating according to UL 94 (Dimensions) | V0 |
Product Description
Terminal block for printed circuit board, nominal current: 76 A, dimensioning voltage (III/2): 1000 V, nominal section: 16 mm², Number of potentials: 2, Number of rows: 1, Number of poles per row: 2,
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
