MKDSN 1,5/ 9 SSC
MKDSN 1,5/ 9 SSC 1715282 PHOENIX CONTACT PCB terminal block, pitch: 5 mm, number of positions: 9, color: gre..
$0.00USD
4547 in stock
Key Specifications
GTIN:4055626405285
Orderkey:1715282
Packing unit:1
ETIM 5.0 (eCl@ss):EC002643
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4055626405285 |
| Orderkey | 1715282 |
| Packing unit | 1 |
| ETIM 5.0 (eCl@ss) | EC002643 |
| ETIM 6.0 (eCl@ss) | EC002643 |
| ETIM 7.0 (eCl@ss) | EC002643 |
| Custom tariff number | 85369010 |
| Pitch (Item properties) | 5 mm |
| (Packaging information) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| eCl@ss 5.1 (Classifications) | 27261100 |
| eCl@ss 6.0 (Classifications) | 27261100 |
| eCl@ss 7.0 (Classifications) | 27440401 |
| eCl@ss 8.0 (Classifications) | 27440401 |
| eCl@ss 9.0 (Classifications) | 27440401 |
| Dimension a (Item properties) | 40 mm |
| Pin spacing (Item properties) | 5 mm |
| Width [ w ] (Item properties) | 45 mm |
| Height [ h ] (Item properties) | 13.5 mm |
| Length [ l ] (Item properties) | 8.1 mm |
| Pin layout (Key Commercial Data) | Linear pinning |
| Solder pin [P] (Item properties) | 3.5 mm |
| China RoHS (Packaging information) | Environmentally Friendly Use Period = 50 |
| REACh SVHC (Packaging information) | |
| Pin spacing (Dimensions for the product) | 5 mm |
| Number of positions (Key Commercial Data) | 9 |
| Hole diameter (Dimensions for the product) | 1.3 mm |
| Drive form screw head (Key Commercial Data) | Slotted |
| Height (without solder pin) (Item properties) | 10 mm |
| Type of packaging (Dimensions for PCB design) | packed in cardboard |
| Pieces per package (Dimensions for PCB design) | 100 |
| Denomination packing units (Dimensions for PCB design) | Pcs. |
Product Description
Terminal block for printed circuit board, rated current: 13.5 A, rated voltage (III/2): 400 V, rated cross-section: 1.5 mm², number of rows: 1, number of poles per row: 9, article family: MKDSN 1.5, p
