MKDSN 1,5/ 8 BD:-8
MKDSN 1,5/ 8 BD:-8 1093276 PHOENIX CONTACT PCB terminal block, nominal current: 13.5 A, rated voltage (III/2..
$0.00USD
3057 in stock
Key Specifications
GTIN:4055626909875
Orderkey:1093276
(Drawings):
Packing unit:1
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4055626909875 |
| Orderkey | 1093276 |
| (Drawings) | |
| Packing unit | 1 |
| Pitch (Drawings) | 5 mm |
| ETIM 5.0 (eCl@ss) | EC002643 |
| ETIM 6.0 (eCl@ss) | EC002643 |
| ETIM 7.0 (eCl@ss) | EC002643 |
| Custom tariff number | 85369010 |
| (Ambient conditions) | Test passed |
| Pin layout (Drawings) | Linear pinning |
| Mounting type (Drawings) | Wave soldering |
| Note (Connection capacity) | WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 |
| Number of levels (Drawings) | 1 |
| Connection method (Drawings) | Screw connection with tension sleeve |
| Note (Packaging information) | For safe conductor connection, always adhere to a defined tightening torque. Particularly in the case of PCB terminal blocks with two or three positions, the individual solder pin for each contact point cannot compensate for this. That is why the terminal blocks must be supported during conductor connection (held with one hand, support on the housing). |
| Range of articles (Drawings) | MKDSN 1,5 |
| eCl@ss 8.0 (Classifications) | 27440401 |
| eCl@ss 9.0 (Classifications) | 27440401 |
| Nom. voltage (Item properties) | 400 V |
| Number of positions (Drawings) | 8 |
| Torque (Electrical parameters) | 0.5 Nm ... 0.6 Nm |
| Pitch (Material data - housing) | 5 mm |
| Drive form screw head (Drawings) | Slotted (L) |
| Specification (Electrical tests) | IEC 60947-1:2007-06 + A1:2010-12 + A2:2014-09 |
| Caption (Material data - housing) | Schematic representation – for additional information, see product range drawing in the Download Center |
| pluggable (Electrical parameters) | no |
| Test specification (Pull-out test) | IEC 60947-7-4 |
| (Termination and connection method) | 1.5 mm² / solid / > 40 N |
| Brief article description (Drawings) | PCB terminal block |
| Type of note (Packaging information) | Note on application |
| Dimension a (Material data - housing) | 35 mm |
| Pin spacing (Material data - housing) | 5 mm |
| Width [ w ] (Material data - housing) | 40 mm |
| Contact material (Connection capacity) | Cu alloy |
| Height [ h ] (Material data - housing) | 13.5 mm |
| Length [ l ] (Material data - housing) | 8.1 mm |
| Pin dimensions (Material data - housing) | 0.5 x 1 mm |
| Pin spacing (Dimensions for the product) | 5 mm |
| Solder pin [P] (Material data - housing) | 3.5 mm |
| Stripping length (Electrical parameters) | 6 mm |
| Connection method (Electrical parameters) | Screw connection with tension sleeve |
| Hole diameter (Dimensions for the product) | 1.3 mm |
| Dimensional drawing (Material data - housing) | |
| Insulating material (Material data - contact) | PA |
| Rated surge voltage (II/2) (Electrical tests) | 4 kV |
| Surface characteristics (Connection capacity) | Tin-plated |
| Type of packaging (Dimensions for PCB design) | packed in cardboard |
| Pieces per package (Dimensions for PCB design) | 50 |
| Rated surge voltage (III/2) (Electrical tests) | 4 kV |
| Rated surge voltage (III/3) (Electrical tests) | 4 kV |
| Pull-out test (Termination and connection method) | IEC 60999-1:1999-11 |
| Rated insulation voltage (II/2) (Electrical tests) | 630 V |
| Insulating material group (Material data - contact) | I |
| Note on connection cross section (Electrical tests) | With connected conductor 1.5 mm² (solid). |
| Rated insulation voltage (III/2) (Electrical tests) | 400 V |
| Rated insulation voltage (III/3) (Electrical tests) | 250 V |
| CTI according to IEC 60112 (Material data - contact) | 600 |
| Clearances and creepage distances (Electrical tests) | IEC 60947-1:2007-06 + A1:2010-12 + A2:2014-09 |
| Result (Current carrying capacity / derating curves) | Test passed |
| Conductor cross section solid (Electrical parameters) | 0.14 mm² ... 1.5 mm² |
| Height (without solder pin) (Material data - housing) | 10 mm |
| Specification (Air clearances and creepage distances) | IEC 60947-7-4 |
| Denomination packing units (Dimensions for PCB design) | Pcs. |
| Rated current (Mechanical tests according to standard) | 13.5 A |
| Amplitude (Current carrying capacity / derating curves) | 0.35 mm (10 - 60.1 Hz) |
| Frequency (Current carrying capacity / derating curves) | 10 - 150 - 10 Hz |
| Conductor cross section flexible (Electrical parameters) | 0.14 mm² ... 1.5 mm² |
| Minimum creepage distance value (II/2) (Electrical tests) | 3.2 mm |
| Sweep speed (Current carrying capacity / derating curves) | 1 octave/min |
| Acceleration (Current carrying capacity / derating curves) | 5 g (60.1 - 150 Hz) |
| Minimum creepage distance value (III/2) (Electrical tests) | 3 mm |
| Minimum creepage distance value (III/3) (Electrical tests) | 3.2 mm |
| Conductor cross section AWG / kcmil (Electrical parameters) | 26 ... 16 |
| Specification (Current carrying capacity / derating curves) | IEC 60068-2-6:2007-12 |
| Ambient temperature (assembly) (General product information) | -5 °C ... 100 °C |
| Ambient temperature (operation) (General product information) | -40 °C ... 100 °C (Depending on the current carrying capacity/derating curve) |
| Test for conductor damage and slackening (Ambient conditions) | IEC 60999-1:1999-11 |
| Metal surface soldering area (top layer) (Connection capacity) | Tin (5 - 7 µm Sn) |
| Metal surface terminal point (top layer) (Connection capacity) | Tin (5 - 7 µm Sn) |
| Rated voltage (III/2) (Mechanical tests according to standard) | 400 V |
| Conductor cross section (Mechanical tests according to standard) | 1.5 mm² |
| Flammability rating according to UL 94 (Material data - contact) | V0 |
| Metal surface soldering area (middle layer) (Connection capacity) | Nickel (2 - 3 µm Ni) |
| Metal surface terminal point (middle layer) (Connection capacity) | Nickel (2 - 3 µm Ni) |
| Minimum clearance - inhomogeneous field (II/2) (Electrical tests) | 3 mm |
| Minimum clearance - inhomogeneous field (III/2) (Electrical tests) | 3 mm |
| Minimum clearance - inhomogeneous field (III/3) (Electrical tests) | 3 mm |
| 2 conductors with same cross section, solid (Electrical parameters) | 0.14 mm² ... 0.75 mm² |
| Rated surge voltage (III/2) (Mechanical tests according to standard) | 4 kV |
| Test duration per axis (Current carrying capacity / derating curves) | 2.5 h |
| Ambient temperature (storage/transport) (General product information) | -40 °C ... 70 °C |
| 2 conductors with same cross section, flexible (Electrical parameters) | 0.14 mm² ... 0.75 mm² |
| Glow wire flammability index GWFI according to EN 60695-2-12 (Material data - contact) | 850 |
| Glow wire ignition temperature GWIT according to EN 60695-2-13 (Material data - contact) | 775 |
| Conductor cross section / conductor type / tensile force (Termination and connection method) | 0.14 mm² / flexible / > 10 N |
| Conductor cross section, flexible, with ferrule, with plastic sleeve (Electrical parameters) | 0.25 mm² ... 1.5 mm² |
| Temperature for the ball pressure test according to EN 60695-10-2 (Material data - contact) | 125 °C |
| Conductor cross section flexible, with ferrule without plastic sleeve (Electrical parameters) | 0.25 mm² ... 1 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve (Electrical parameters) | 0.25 mm² ... 0.5 mm² |
| 2 conductors with same cross section, stranded, with TWIN ferrules with plastic sleeve (Electrical parameters) | 0.5 mm² ... 0.75 mm² |
Product Description
Terminal block for printed circuit board, nominal current: 13.5 A, nominal voltage (III/2): 400 V, nominal section: 1.5 mm², number of rows: 1, number of poles per row: 8, article family: MKDSN 1.5, p
