MBEK5A5BCV
MBEK5A5BCV PANASONIC Driver Brushless MINAS BL, KV series (speed control), RS485 port, NPN input signal, 50W..
$0.00USD
3460 in stock
Key Specifications
Item:Specifications
Series:MBEK
Product:Brushless Amplifier
Features:Speed control type, 50 W・100 W・200 W・400 W・750 W, Input power supply for Amplifier: Voltage AC 100 V/200 V, Rated speed 3000 r/min
Supplier Information
PANASONIC
Products: 4316
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Item | Specifications |
| Series | MBEK |
| Product | Brushless Amplifier |
| Features | Speed control type, 50 W・100 W・200 W・400 W・750 W, Input power supply for Amplifier: Voltage AC 100 V/200 V, Rated speed 3000 r/min |
| Mass (kg) | 0.37 |
| Part Number | MBEK5A5BCV |
| Product name | MINAS-BL KV Series |
| Signal input | 5 inputs*(run/ stop, CW run/ CCW run, multi function 3 bit) |
| Signal output | 2 outputs (Open collector)*(Trip output etc) |
| Control method | Speed control |
| Supply voltage | Single/3-phase AC200 V to 240 V |
| Protection level | Protection level: torque command 115 ％ (inverse time characteristics) |
| Motor rated output | 50 W |
| Regenerating brake | Externally connected |
| Power cable included | without |
| Communication function | RS485 |
| Speed control range (r/min) | 100 to 4000 (Speed ratio 1:133)*Adjustment of the parameters is necessary depending on the workload conditions. |
| Rated rotation speed (r/min) | 3000 |
| Acceleration/ Deceleration time | 0.01 sec to 300 sec*(time for changing 1000 r/min) |
| Protection structure/ Cooling system | Equivalent to IP20/ Self cooling |
| Speed fluctuation factor : With load | ±0.5 % or below (at 0 to Rated torque, Rated rotation speed) |
| Speed fluctuation factor : With voltage | ±0.5 % or below (at supply voltage ±10 %, rated rotation speed) |
| Speed fluctuation factor : With temperature | ±0.5 % or below (at 0 ℃ to 50 ℃, rated rotation speed) |
Product Description
MBEK5A5BCV_Brushless Amplifier_MINAS-BL KV Series
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
