M22-FG

M22 IndicatorsNut-mounted, 22 mm indicator,with high visibility, illuminated buttonsThe M22 series of indicators comes in 22 or 25 mm-diameterround versions. They can be easily mountedand removal of the socket unit is also easy.The finger protection mechanism on the lamp is provided as a standardfeature. M22 indicators can be equippedwith an LED or incandescent lamp.• Available in 5 colors• Super-bright LEDs forallversions• Lamp sockets with or without transformers•UL andcUL approvedOrdering informationDisplayAppearance IP65 oil-resistantColor of displayOrder codeRound/flat Red M22-FRLampAC/DC LEDlightOperating voltage6 V 12 V 24 V 24 VsuperbrightGreen M22-FG YellowM22-FY White M22-FW Blue M22-FASquare/projectionRed M22-CR Green M22-CG YellowM22-CY White M22-CW Blue M22-CASocket unitOrder codeVoltage-reduction circuitsWithout voltage reduction unit With voltage reduction unit (220 VAC)M22-00M22-00-T2AC RedA22-6DR –––Green A22-6DG––– YellowA22-6DY ––– BlueA22-6DA–––DC RedA22-6AR ––– Green A22-6AG ––– Yellow A22-6AY ––– BlueA22-6AA–––AC and DCRed –A22-12AR A22-24AR A22-24ASR Green –A22-12AGA22-24AGA22-24ASG Yellow–A22-12AY A22-24AY A22-24ASY Blue–A22-12AA A22-24AA A22-24ASAIncandescent lamp 6 VAC/VDC12 VAC/VDC24 VAC/VDC100 VAC/VDCA22-5 A22-12 A22-24 A22-H1AccessoriesM22 uses the same accessories as A22. Please refer to the relevantinformationin the correspondingsection for the A22.SpecificationsRecognized organization Standards File numberUL, cUL UL508 E41515LED lampRated voltageRated current Operating voltage6 VDC60 mA (20 mA) 6 VDC ±5%6 VAC60 mA (20 mA) 6 VAC ±5%12 VAC/VDC30 mA (10 mA)12 VAC/VDC ±5%24 VAC/VDC15 mA (10 mA)24 VAC/VDC ±5%Incandescent lampRated voltageRated current Operating voltage6 VAC/VDC 200 mA 5 V14 VAC/VDC 80 mA12 V28 VAC/VDC 40 mA24 V130 VAC/VDC 20 mA100 VSuperbright LED indicatorRated voltageRated current Operating voltage24 VAC/VDC 15 mA24 VAC/VDC ±5%Voltage-reduction lightingRated voltageRated current Operating voltage110 VAC 95 to 115VAC LED lamp (A22-24_)220 VAC 190 to 230 VACAmbient temperature Operating: –20 to 55°C, storage: –40 to 70°CDegree of protection IP65Electric shock protection classClass IIPTI (tracking characteristic)175Degree of contamination3 (IEC947-5-1)Size in mmButton: 29.7 dia. × 16D, switch: 34H × 34W × 54.7D671
