In Stock Hot Product
LPC-150-2450
LPC-150-2450 MEANWELL AC-DC Single output LED driver Constant Current (CC), Universal AC input, Output 2.45A..
$0.00USD
3343 in stock
Key Specifications
Name:LPC-150-2450
Format:Box
Series:LPC-150
Approvals:EC
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | LPC-150-2450 |
| Format | Box |
| Series | LPC-150 |
| Approvals | EC |
| Power (W) | 151,90 |
| Subformato | IP67 |
| Width (mm) | 63.00 |
| Height (mm) | 37.50 |
| AC input Max | 305,00 |
| AC input Min | 180,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | LED Driver |
| Isolation (V) | 3.000,00 |
| Peak Power (W) | 151.9 |
| Input connector | Cable |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 191.00 |
| Long Description | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in box waterproof plasticIP67.Input range180-305Vca47-63Hz.Output in constant currentIs 2.45 A.Range of output voltage with current mode constant31 to 62Vccaccording to demand load.Power:151,9 W.Efficiency typical:90%.Input class II without grounding.Operating temperature range of caseTcfrom-25ºCup+50ºC.Dimensions (Length x Width x Height):191 x 63 x 37.5 mm2 years of warranty.Manufacturer: MEAN WELL.Series LP-C and LPC are LED Drivers designed to work directly with LEDs (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream. With plastic housing, water-tight (IP67). Suitable for decorative lighting, architectural, LED indicators, theaters and electronic billboards.Have a low cost and a high reliability. Small and compact size. |
| Output connector | Cable |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 2,00 |
| Country of Origin | China |
| Output current mA | 2400, 2500 |
| Intensity of Minimum Output (mA) | 2.450,00 |
| Intensity of Output Maximum (mA) | 2.450,00 |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
LED driver.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
