KAA-8R
KAA-8R MEANWELL 8-fold Universal Switching Actuator, 16A per channel
$0.00USD
3217 in stock
Key Specifications
Name (Details):KAA-8R
State (Details):New
Stock (Details):Yes
Format (Details):Din Rail
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name (Details) | KAA-8R |
| State (Details) | New |
| Stock (Details) | Yes |
| Format (Details) | Din Rail |
| Series (Details) | KAA-8R |
| Approvals (Details) | EC |
| Subformato (Details) | Ladder |
| Width (mm) (Details) | 72.00 |
| Height (mm) (Details) | 90.00 |
| No. Outputs (Details) | Eight |
| Applications (Details) | Building automation, Lighting, Industrial |
| Manufacturer (Details) | MEAN WELL |
| Product type (Details) | Actuator |
| Input connector (Details) | Quick Connector |
| Long/Background (Details) | 57.00 |
| Long Description (Details) | Actuator KNX 8-channel.Functions of scenes and time programmable.Format to install on a Din rail.Self-powered from the bux KNX (21-31V)Consumption of entry to <180mW.8 relay outputsfree of potential16 Amps.Maximum capacitive load per output 220µF.Voltage relay 230vac 50Hz.Maximum currenttotal output80A.Mechanical life operating>10Six.Button for programming individial address.Working temperature: from-30ºCup+45 ° Cof ambient temperature.Dimensions (Width x Height x depth):72 x 90 x 57mm. 4UWidth Din rail.3 years warranty.Manufacturer: MEAN WELL.CLICK VIDEO KAA-8R KNX.The actuators of the series KAA-8R allows the independent control of relays to control lighting, heating, ventilation, blinds, etc.. they Have a compact size with a width of 72mm (4U), suitable for distribution boards, EIB and KNX. The equipment is self-powered from the KNX bus. The relays are especially designed for inductive loads, such as motors and blinds. The device is programmed using the software ETS5.0 and drivers, can be downloaded from the page of KNX http://www.meanwell.com/productCatalog.aspxThe series KAA-8R is ideal for automation and control solutions for smart buildings. |
| Output connector (Details) | Screw-Type |
| Warranty (Years) (Details) | 3,00 |
| Country of Origin (Details) | China |
| Current per channel (A) (Details) | Sixteen |
| Maximum Current Total (A) (Details) | Eighty |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Actuator KNX 8-channel.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
