K8DT-TH2CD
K8DT-TH2CD K8DT0060B 669505 OMRON Monitoring relay Temperature 0-1700ºC/F 24V AC/DC SPDT 17.5mm Push-in+
$0.00USD
4770 in stock
Key Specifications
Size:17.5 mm
Terminal:Push-in
Functions:ON/OFF control, Temperature
Body color:Black
Supplier Information
OMRON
Products: 41472
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Size | 17.5 mm |
| Terminal | Push-in |
| Functions | ON/OFF control, Temperature |
| Body color | Black |
| Output type | Relay |
| Installation type | DIN Rail |
| Supply voltage AC | 20.4-26.4 V |
| Supply voltage DC | 20.4-26.4 V |
| Temperature range | 0-1800 °C |
| Contact description | SPDT |
| Temperature input type | B, E, J, K, P (PLII), R, S, T |
Product Description
Monitoring relay 17.5mm wide, over or under temperature, 0 to 1700 °C/F(minimum setting 10 °C), Thermocouple input type, 1 x SPDT, 24 V AC/DC
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
