K8AB-VS1 200/230VAC
K8AB-VS1 200/230VAC 181871 OMRON
$0.00USD
4169 in stock
Key Specifications
EMC (3-phase sequence, phase-loss relay):EN 60947-5-1
Weight (3-phase sequence, phase-loss relay):Approx. 130 g
Altitude (3-phase sequence, phase-loss relay):2,000 m max.
Indicators (3-phase sequence, phase-loss relay):Power (PWR): Green LED, relay output (RY): Yellow LED
Supplier Information
OMRON
Products: 41472
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EMC (3-phase sequence, phase-loss relay) | EN 60947-5-1 |
| Weight (3-phase sequence, phase-loss relay) | Approx. 130 g |
| Altitude (3-phase sequence, phase-loss relay) | 2,000 m max. |
| Indicators (3-phase sequence, phase-loss relay) | Power (PWR): Green LED, relay output (RY): Yellow LED |
| Case material (3-phase sequence, phase-loss relay) | PC and ABS |
| 200 to 480 VAC (3-phase sequence, phase-loss relay) | K8AK-PH1 |
| Electrical life (3-phase sequence, phase-loss relay) | 50,000 operations at 5 A, 250 VAC or 30 VDC |
| Input frequency (3-phase sequence, phase-loss relay) | 50/60 Hz (AC power supply) |
| Mechanical life (3-phase sequence, phase-loss relay) | 10,000,000 operations |
| Resetting method (3-phase sequence, phase-loss relay) | Automatic reset |
| Safety standards (3-phase sequence, phase-loss relay) | UL 508 (Recognition), Korean Radio Waves Act (Act 10564), CSA and CCC |
| Overload capacity (3-phase sequence, phase-loss relay) | Continuous input: 528 VAC |
| Rated input voltage (3-phase sequence, phase-loss relay) | Three-phase, three-wire mode, 200 to 480 VAC |
| Storage temperature (3-phase sequence, phase-loss relay) | -25 to 65°C (with no condensation or icing) |
| Applicable standards (3-phase sequence, phase-loss relay) | Conforming standards |
| Degree of protection (3-phase sequence, phase-loss relay) | Terminal section: IP20 |
| Maximum contact current (3-phase sequence, phase-loss relay) | 5 A |
| Maximum contact voltage (3-phase sequence, phase-loss relay) | 250 VAC or 30 VDC |
| Size in mm (H × W × D) (3-phase sequence, phase-loss relay) | 90 × 22.5 × 100 |
| Maximum switching capacity (3-phase sequence, phase-loss relay) | 1,250 VA, 150W |
| Ambient operating temperature (3-phase sequence, phase-loss relay) | -20 to 60°C (with no condensation or icing) |
| Reversed phase and phase loss operating time (3-phase sequence, phase-loss relay) | 0.1 s max. |
| Output relays(1 × DPDT, normally closed operation) (3-phase sequence, phase-loss relay) | Resistive load |
Product Description
No description available for this product.
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
The K8AK-PH1 monitoring relay is designed to monitor 3-phase 3-wire supplies. It simultaneously monitors phase sequence and phase loss during start up as well as phase loss during operation. The output relay releases when alarm conditions are detected, and the warning status can easily be monitored using the LED indicator. Suitable for industrial facilities and equipment.
