IRM-03-24
IRM-03-24 MEANWELL AC-DC Single Output Encapsulated power supply, PCB mount, Input range 85-305VAC, Output 2..
$0.00USD
4612 in stock
Key Specifications
Name:IRM-03-24
State:New
Format:For Printed Circuit
Series:IRM-03
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | IRM-03-24 |
| State | New |
| Format | For Printed Circuit |
| Series | IRM-03 |
| Approvals | CE, UL |
| Power (W) | 3,00 |
| Width (mm) | 24.00 |
| Height (mm) | 15.00 |
| AC input Max | 305,00 |
| AC input Min | 85,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 3.000,00 |
| Output voltage | 24,00 |
| Peak Power (W) | Three |
| Input connector | Pin |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 37.00 |
| Long Description | Switching Power supply for Printed Circuit board.Range of Universal Input85-305Vca47-63Hz.Output voltage24vdc.Output intensity125mA.Range of output current 0-125mA according to demand load.Power:3W.Efficiency typical:80%.Consumption without load <0,075 W.Input class II without grounding.Operating temperature range of caseTcfrom-30up+85ºC.Dimensions (Length x Width x Height) [mm]:37 x 24 x 15.3 years of warranty.Manufacturer: MEAN WELL.The serial MRI are sources of compact size to integrate on-board by soldering its pins into the holes of the PCB.This source is a class II non-grounded with double reinforced insulation.Has a minimum consumption without load which allows you to meet the requisitivos of ecological design with a small consumption in stand-by.It is CE certified and UL listed as power equipment limited "LPS".It has protection against over loads, short circuits and over-voltage output.Complies with EN55022 Class B without the need for additional components, although you should always verify the final design of the plate. |
| Output connector | Pin |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Switching Power supply for Printed Circuit board.
