IL1/CP-4A
IL1/CP-4A MICRO DETECTORS Inductive sensor unshielded PNP NC cable 2m 90°
$0.00USD
3174 in stock
Key Specifications
Weight:63g
Mounting:Shielded
Approvals:CE
Dimensions:28 x 16 x 10,3
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 63g |
| Mounting | Shielded |
| Approvals | CE |
| Dimensions | 28 x 16 x 10,3 |
| Hysteresis | 1 … 20% |
| Connections | 2m PVC Cable |
| Output type | PNP |
| Load current | ≤ 300mA |
| LED indicators | Yellow LED output state |
| Leakage current | ≤ 0,12mA |
| Output Function | NC |
| Repeat Accuracy | 5% (UB 24V Ta=23°C ±5°C) |
| Standard target | 12x12mm FE360 |
| Housing Material | PA |
| Correction Factor | copper: 0,41 / aluminium: 0,50 / brass: 0,55 / stainless steel: 0,75 |
| EMC compatibility | IEC 60947-5-2 |
| Operating Voltage | 10 - 30Vdc |
| Max ripple content | ≤10% |
| Operanting distance | 0…2,4mm |
| Output voltage drop | ≤ 1,5V @100mA |
| Switching frequency | 3kHz |
| Thermal drift of Sr | < 10% |
| Active Head Material | PA |
| Degree of protection | IP 67 (EN60529) |
| Operating temperature | -25°C…+70°C |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| No-Load supply current | ≤ 10mA |
| Nominal sensing distance | 3mm |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Time delay before availability | ≤ 100ms |
| Protection against inductive loads | Yes |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
