In Stock Hot Product
IDLC-65-1050DA
IDLC-65-1050DA MEANWELL AC-DC Constant Current LED Driver (CC) with PFC, Output 62VDC / 1.05A, Dimming with ..
$0.00USD
3167 in stock
Key Specifications
Name:IDLC-65-1050DA
State:New
Format:Box
Series:IDLC-65-DA
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | IDLC-65-1050DA |
| State | New |
| Format | Box |
| Series | IDLC-65-DA |
| Dimming | DALI |
| Approvals | CCC, CE, ENEC, UL |
| Power (W) | 65,10 |
| Subformato | IP20 |
| Width (mm) | 75.00 |
| Height (mm) | 25.00 |
| AC input Max | 295,00 |
| AC input Min | 180,00 |
| Applications | Lighting |
| Manufacturer | MEAN WELL |
| Product type | LED Driver |
| Isolation (V) | 3.750,00 |
| Peak Power (W) | 65.1 |
| Input connector | Quick Connector |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 130.00 |
| Long Description | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format in plastic boxIP20.Input range180-295Vca47-63Hz.Output in constant current1050mA.Range of output voltage with current mode constant46 to 62Vccaccording to demand load.Power:65,1 W.Efficiency typical:87%.Regulation DALI0% to 100% of the output intensity. Certificate to DALI.Input class II without grounding.Factor corrector, power>0.95to 230vac at full load.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-20ºCup+85ºC.Dimensions (Length x Width x Height):130 x 75 x 25mm.3 years of warranty.Manufacturer: MEAN WELL.The series IDLC are LED drivers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream. With plastic housing designed for lighting applications in interior. Low ripple current, no flicker (flicker-free).This source works on a Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.Compatible with any system DALI. |
| Output connector | Quick Connector |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
| Output current mA | One thousand fifty |
| Intensity of Minimum Output (mA) | 1.050,00 |
| Intensity of Output Maximum (mA) | 1.050,00 |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
LED driver dimmable.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
