HRPG-300-12
HRPG-300-12 MEANWELL AC-DC Single output enclosed power supply, Output 12VDC / 27A, 1U low profile, fan cool..
$82.27USD
164 in stock
Key Specifications
Fan:Yes
Name:HRPG-300-12
Alarms:Output OK
Format:Box
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Fan | Yes |
| Name | HRPG-300-12 |
| Alarms | Output OK |
| Format | Box |
| Series | HRPG-300 |
| Approvals | CE, UL |
| Power (W) | 324,00 |
| Subformato | Grid |
| Width (mm) | 105.00 |
| Height (mm) | 41.00 |
| AC input Max | 264,00 |
| AC input Min | 85,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 3.000,00 |
| Output voltage | 12,00 |
| Peak Power (W) | Three hundred twenty four |
| Input connector | Screw-Type |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 199.00 |
| Long Description | Power supply in the format box.Format in box.Range of universal input85-264vac. 47-63Hz.Output voltage12vdc. Adjustable by potentiometer (10,2-13,8 Vdc).Output intensity27A. Range of output current 0-27A according to demand load.Power:324W.Efficiency typical:88%.Supports peak input voltage of 300Vca for 5 seconds.Factor corrector, power>0,95to 230vac and full load.Alarm output voltage to the correct DC-Ok.Remote on / off.Auxiliary output Stand-by 5V 0.3 A.Function of sensing to compensate the voltage drop in the cables.Consumption without load <0.5 W.Working temperature: from-40up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:199 x 105 x 41.5 years of warranty.Manufacturer: MEAN WELL.The series HRPG are the sources of most high-end format box MEAN WELL. Are designed for demanding applications.Support input voltages of 300Vca for 5 seconds and use components of the highest reliability as the electrolytic capacitors of 105ºC.The protection against over loads is for current limiting, constant current, and can reduce stress by up to 50% of its nominal value and keeping the output intensity, this serves to start heavy loads such as motors or other inductive loads or capacitive. |
| Output connector | Screw-Type |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 5,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Power supply in the format box.
