HLG-320H-C3500DA
HLG-320H-C3500DA MEANWELL AC-DC Single output LED driver Constant Current (CC) with built-in PFC, Output 91V..
$0.00USD
4461 in stock
Key Specifications
Name:HLG-320H-C3500DA
State:Recommended Model
Format:Box
Series:HLG-320H-C-DA
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | HLG-320H-C3500DA |
| State | Recommended Model |
| Format | Box |
| Series | HLG-320H-C-DA |
| Dimming | DALI |
| Approvals | CCC, CE, ENEC, UL |
| Power (W) | 318,50 |
| Subformato | IP67 |
| Width (mm) | 90.00 |
| Height (mm) | 43.80 |
| AC input Max | 305,00 |
| AC input Min | 90,00 |
| Applications | Lighting |
| Manufacturer | MEAN WELL |
| Product type | LED Driver |
| Isolation (V) | 3.750,00 |
| Peak Power (W) | 318.5 |
| Input connector | Cable |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 252.00 |
| Long Description | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output in constant current3.5 A.Range of output voltage with current mode constant46 to 91Vccaccording to demand load.Power:318,5 W.Efficiency typical:94%.Regulation DALI0% to 100% of the output current with regulation DALI. Certificate to DALI.Factor corrector, power>0.95to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+85ºC.Dimensions (Length x Width x Height):252 x 90 x 43.8 mm7 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.The series HLG are LED drivers, class I grounded.With metal housing, waterproof to IP67. The series HLG has a high efficiency designed for applications of public lighting, architectural, exterior, interior or any lighting application LED needs a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. Suitable for LED lighting or LED displays. Complies with the requirements of security at the global level for lighting.Compatible with any system DALI. |
| Output connector | Cable |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 7,00 |
| Country of Origin | China |
| Output current mA | Three thousand five hundred |
| Intensity of Minimum Output (mA) | 3.500,00 |
| Intensity of Output Maximum (mA) | 3.500,00 |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
LED driver dimmable.
