HJ2-L-T-DC24
HJ2-L-T-DC24 AHJ222206 PANASONIC Power-Relay, 2-Form-C, Single side stable, Plug-in, LED, Test Button
$0.00USD
4637 in stock
Key Specifications
Item:Specifications
Details:With a test button, Without Au plating, With LED indication
Features:Relay for control panel of 2c 7A and 4c 5A
Accessories:Sockets and terminal sockets are available.
Supplier Information
PANASONIC
Products: 4316
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Item | Specifications |
| Details | With a test button, Without Au plating, With LED indication |
| Features | Relay for control panel of 2c 7A and 4c 5A |
| Accessories | Sockets and terminal sockets are available. |
| Part Number | AHJ222206 |
| Coil voltage | 24V DC |
| Product name | HJ Relays(Discontinued) |
| Product Number | HJ2-L-T-DC24V |
| Pick-up voltage | 19.2V DC |
| Contact material | Ag |
| Drop-out voltage | 2.4V DC |
| Type of operation | BBM |
| Operating function | Single Side Stable Type |
| Ambient temperature | -40deg to +70deg |
| Contact arrangement | 2 Form C |
| Terminal arrangment | Plug-in terminal |
| Type classification | With a test button |
| Operation indication | With LED indication |
| Contact specification | Without Au plating |
| Min. switching capacity | 1mA 5V DC |
| Nominal Operating Power | 900mW |
| Protective construction | Dust Cover Type |
| Expected life (Electrical) | 1x10^5 |
| Breakdown voltage (Contact-Coil)(Initial) | 2000Vrms |
| Expected life (Mechanical) (Min.operation) | 2x10^7 |
| Nominal switching capacity (Resistive load) | 7A 250V AC, 7A 30V DC |
| Breakdown voltage (Contact-Contact)(Initial) | 1000Vrms |
