HC-K12/2-ESTC-WS

Parameter	Value
	B32
Width	34 mm
Height	39.6 mm
Series	HC-K
General	For HEAVYCON-ADVANCE and HEAVYCON housings of B16/B32 construction, power contacts: CK 4.0-ED, control contacts: CK 1.6-ED (crimped contacts not included in the scope of delivery)
Longitude	84.5 mm
Plug Face	12+2+PE
Construction	B16
Product Type	Fixed pole contact insert
Rated Current	40 A (Power Contacts)
Surge Category	Iii
Connection type	Crimp connection
Number of poles	14
Contact Diameter	4 mm
Contact material	Cu Alloy
Dimension Scheme
Tightening torque	0.8 Nm ... 1.2 Nm (PE connection)
Connection Section	1.5 mm² ... 6 mm² (Power Contacts)
Degree of pollution	3
Connection technology	Crimp Connection (Power Contacts)
AWG Connection Section	16 ... 10 (Power Contacts)
Sizing voltage (III/3)	690 V (Power Contacts)
Horizontal Hole Spacing	77.5 mm
Contact Support Material	PC
Number of Power Contacts	12
Type of contact material	Machining
Installation instructions	Proper use requires mounting in a housing with IP54 or higher degree of protection
Number of control contacts	2
Ambient Temperature (Service)	-40 °C ... 125 °C
Dimensioning Transient Voltage	8 kV (Power Contacts)
Flammability class according to UL 94	V0
Material: Contact Surface, Power Contact	Ag
Material: contact surface, control contact	Ag (alternatively Au)
Length to be de-isolated from the individual conductor	9 mm (Capacity 1.5 mm²\|... 2.5 mm²)

More details

Technical specifications and performance data

Installation and operation guide

HC-K12/2-ESTC-WS 1497713 PHOENIX CONTACT Contact insert, number of poles: 12+2+PE, size: B16, power contacts..
