In Stock Hot Product
H5CC-A11F
H5CC-A11F H5CC0009H H5CCA11F OMRON Timer, plug-in, 11-pin, DIN 48x48 mm, standard type, No-voltage (NPN) inp..
$0.00USD
3256 in stock
Key Specifications
():Y92F-45
Size:1/16 DIN (48 x 48 mm)
Type:Digital
Inputs:Gate (NPN/PNP), Reset (NPN/PNP), Signal (NPN/PNP)
Supplier Information
OMRON
Products: 41472
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| () | Y92F-45 |
| Size | 1/16 DIN (48 x 48 mm) |
| Type | Digital |
| Inputs | Gate (NPN/PNP), Reset (NPN/PNP), Signal (NPN/PNP) |
| Terminal | Plug-in |
| Functions | Multi-functional |
| Output type | Relay |
| Operating mode | Flicker OFF Start (Signal Start), Flicker ON Start (Signal Start), Interval (Signal Start), OFF Delay (Signal), ON Delay (Power ON Start), ON Delay (Signal Start), Signal ON/OFF Delay |
| Installation type | DIN Rail, On-panel, Socket |
| Supply voltage AC | 24-240 V |
| Supply voltage DC | 24-240 V |
| Contact description | SPDT |
| Number of pin contact | 11 |
Product Description
Timer, plug-in, 11 pins, DIN 48x48 mm, standard type, non-voltage input (NPN)/voltage input (PNP) (switchable), contact output (SPDT time limit), 24 to 240 VDC/24 to 240 VAC power supply
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
