GST25E18-P1J
GST25E18-P1J MEANWELL AC-DC Industrial desktop adaptor, Output 18VDC / 1.38A, 2 Pin Euro plug
$0.00USD
4295 in stock
Key Specifications
Name (Details):GST25E18-P1J
State (Details):Recommended Model
Stock (Details):Yes
Format (Details):Wall
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name (Details) | GST25E18-P1J |
| State (Details) | Recommended Model |
| Stock (Details) | Yes |
| Format (Details) | Wall |
| Series (Details) | GST25 |
| Approvals (Details) | EC, EAC, SIRIM |
| Power (W) (Details) | 25,00 |
| Subformato (Details) | Pin AC European |
| Width (mm) (Details) | 54.00 |
| Height (mm) (Details) | 33.00 |
| AC input Max (Details) | 264,00 |
| AC input Min (Details) | 85,00 |
| Applications (Details) | Industrial, Telecommunications |
| Manufacturer (Details) | MEAN WELL |
| Product type (Details) | Power supply AC/DC |
| Isolation (V) (Details) | 4.242,00 |
| Output voltage (Details) | 18,00 |
| Peak Power (W) (Details) | Twenty five |
| Input connector (Details) | European Plug |
| Input frequency (Details) | 50 Hz, 60 Hz |
| Long/Background (Details) | 79.00 |
| Long Description (Details) | Wall adapter with input plug for Europe.Feeder for connection to a wall outlet.Range of universal input85-264vac47-63Hz.Output voltage18vdc.Output intensity1.38 To. Range of current output 0-1,38 according To the demand load.Power:25W.Efficiency typical:87%.Class ll without the taking of land.Consumption without load<0,075 W.Led indicator of operation.Working temperature: from-30up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:79 x 54 x 33.3 years of warranty.Manufacturer: MEAN WELL.The GST series-AND these sources are switched in the format of a wall with input connector european.The series GST25 have a low consumption, no-load of only 0,075 W and comply with the latest requirements of energy efficiency. |
| Output connector (Details) | P1J Tunnig Fork 5.5 x 2.1 x 11. C+ |
| Type of Entry CA (Details) | Single-phase |
| Warranty (Years) (Details) | 3,00 |
| Country of Origin (Details) | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Wall adapter with input plug for Europe.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
