GSM60U07-P1J
GSM60U07-P1J MEANWELL AC-DC Ultra slim Wall mount medical adaptor, Output 7.5VDC / 6A, Equipped with 2 pin U..
$0.00USD
4511 in stock
Key Specifications
Name (Details):GSM60U07-P1J
State (Details):New
Format (Details):Wall
Series (Details):GSM60U/E
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name (Details) | GSM60U07-P1J |
| State (Details) | New |
| Format (Details) | Wall |
| Series (Details) | GSM60U/E |
| Approvals (Details) | UL |
| Power (W) (Details) | 45,00 |
| Subformato (Details) | Narrow |
| Width (mm) (Details) | Thirty two |
| Height (mm) (Details) | 47.5 |
| AC input Max (Details) | 264,00 |
| AC input Min (Details) | 80,00 |
| Applications (Details) | Industrial, Medical, Telecommunications |
| Manufacturer (Details) | MEAN WELL |
| Product type (Details) | Power supply AC/DC |
| Isolation (V) (Details) | 5.656,00 |
| Output voltage (Details) | 7,50 |
| Peak Power (W) (Details) | Forty five |
| Input connector (Details) | Pin American |
| Input frequency (Details) | 50 Hz, 60 Hz |
| Long/Background (Details) | 75.5 |
| Long Description (Details) | Compact wall adapter with input plug for America.Adaptercertified for medical applications2x MOPP (patient protection).Feeder for connection to a wall outlet.Range of universal input80-264vac47-63Hz.Output voltageTo 7.5 Vdc.Output intensity6A. Range of output current 0-6A according to the demand load.Power:45W.Efficiency typical:85%.Class lI without the taking of land.Consumption without load<0,15 W.Working temperature: from-30up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:75,5 x 32 x 47,5.3 years of warranty.Manufacturer: MEAN WELL.The series GSM60-E are sources switched compact for connection to a wall socket, with input connector american connector type output Jack 5.5 x 2.1 x 11 mm (outer diameter, inner and length), and center positive. (Level VI).The series GSM60 have a low consumption, no-load of only 0.15 W and meet the latest requirements of energy efficiency. |
| Output connector (Details) | P1J Tunnig Fork 5.5 x 2.1 x 11. C+ |
| Type of Entry CA (Details) | Single-phase |
| Warranty (Years) (Details) | 3,00 |
| Country of Origin (Details) | Taiwan |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Compact wall adapter with input plug for America.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
