GL18HB
GL18HB GL-18HB PANASONIC UZQ325, inductive proximity sensor, rectangular shape, 5mm, NC, NPN, cable 1m
$0.00USD
4266 in stock
Key Specifications
Item:Specifications
Cable:0.3 mm23-core oil resistant cabtyre cable, 1 m3.281 ftlong
Output:NPN open-collector transistor- Maximum sink current: 100 mA- Applied voltage: 30 V DC or less (between output and 0 V)- Residual voltage: 1.5 V or less (at 100 mA sink current), 0.4 V or less (at 16 mA sink current)
Weight:Net weight : 45 g approx.
Supplier Information
PANASONIC
Products: 4316
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Item | Specifications |
| Cable | 0.3 mm23-core oil resistant cabtyre cable, 1 m3.281 ftlong |
| Output | NPN open-collector transistor- Maximum sink current: 100 mA- Applied voltage: 30 V DC or less (between output and 0 V)- Residual voltage: 1.5 V or less (at 100 mA sink current), 0.4 V or less (at 16 mA sink current) |
| Weight | Net weight : 45 g approx. |
| Details | GL-18H/18HL type |
| Product | Compact & Low Price Inductive Proximity Sensor |
| Material | Enclosure: Polyarylate |
| Hysteresis | 15 % or less of operation distance (with standard sensing object) |
| Protection | IP67 (IEC), IP67g (JEM) (Note:If using the sensor in an environment where cutting oil droplets splatter, the sensor may be deteriorated due to added substances in the oil.Please check the resistivity of the sensor against the cutting oil you are using beforehand.) |
| Accessories | - |
| Part Number | GL-18HB |
| Product name | Compact & Low Price Inductive Proximity Sensor GL |
| Product Number | GL-18HB |
| Supply voltage | 10 to 30 V DC Ripple P-P 10 % or less |
| Cable extension | Extension up to total 100 m328.084 ftis possible with 0.3 mm2, or more, cable. |
| Ambient humidity | 45 to 85 % RH, Storage: 45 to 85 % RH |
| Shock resistance | 1,000 m/s2acceleration (100 G approx.) in X, Y and Z directions three times each |
| Ambient temperature | -25 to +70 ℃-13 to +158℉,Storage: -25 to +70 ℃-13 to +158℉ |
| Current consumption | 10 mA or less |
| Operation indicator | Red LED (lights up when the output is ON) |
| Stable sensing range | 0 to 4 mm0 to 0.157 in(Note)The maximum operation distance stands for the maximum distance for which the sensor can detect the standard sensing object.The stable sensing range stands for the sensing range for which the sensor can stably detect the standard sensing object even if there is an ambient temperature drift and/or supply voltage fluctuation. |
| Vibration resistance | 10 to 55 Hz frequency, 1.5 mm0.059 indouble amplitude in X, Y and Z directions for two hours each |
| Insulation resistance | 50 MΩ, or more, with 250 V DC megger between all supply terminals connected together and enclosure |
| Max. operation distance | 5 mm0.197 in± 10 %(Note)The maximum operation distance stands for the maximum distance for which the sensor can detect the standard sensing object.The stable sensing range stands for the sensing range for which the sensor can stably detect the standard sensing object even if there is an ambient temperature drift and/or supply voltage fluctuation. |
| Max. response frequency | 1kHz |
| Output:Output operation | Normally closed |
| Standard sensing object | Iron sheet 25 × 25 × t 1 mm0.984 × 0.984 × t 0.039 in |
| Voltage withstandability | 1,000 V AC for one min. between all supply terminals connected together and enclosure |
| Output:Utilization category | DC-12 or DC-13 |
| CE marking directive compliance | EMC Directive, RoHS Directive |
| Environmental resistance:Pollution degree | 3 (Industrial environment) |
| Sensing range variation:Voltage characteristics | Within ±2% for ±10 % fluctuation of the supply voltage |
| Sensing range variation:Temperature characteristics | Over ambient temperature range -25 to +70 ℃-13 to +158℉: within ±10 % of sensing range at +20 ℃+68℉ |
