GKDS/E A0 BK
GKDS/E A0 BK 1706015 PHOENIX CONTACT PCB terminal block
$0.00USD
4533 in stock
Key Specifications
UNSPSC 11 (ETIM):39121432
ETIM 3.0 (eCl@ss):EC001121
ETIM 4.0 (eCl@ss):EC002643
ETIM 5.0 (eCl@ss):EC002643
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| UNSPSC 11 (ETIM) | 39121432 |
| ETIM 3.0 (eCl@ss) | EC001121 |
| ETIM 4.0 (eCl@ss) | EC002643 |
| ETIM 5.0 (eCl@ss) | EC002643 |
| ETIM 6.0 (eCl@ss) | EC002643 |
| (Connection data) | CSA |
| UNSPSC 13.2 (ETIM) | 39121432 |
| UNSPSC 6.01 (ETIM) | 30211801 |
| UNSPSC 12.01 (ETIM) | 39121432 |
| UNSPSC 7.0901 (ETIM) | 39121432 |
| GTIN (Your advantages) | 4017918315313 |
| Note (Your advantages) | Made to Order (non-returnable) |
| Orderkey (Your advantages) | 1706015 |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Packing unit (Your advantages) | 50 pc |
| Screw thread (Key Commercial Data) | M3 |
| Country of origin (Your advantages) | DE (Germany) |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Custom tariff number (Your advantages) | 85369010 |
| Stripping length (Key Commercial Data) | 9 mm |
| Range of articles (Key Commercial Data) | GKDS/E |
| Minimum order quantity (Your advantages) | 50 pc |
| Nominal current IN (Key Commercial Data) | 24 A |
| Solder pin surface (Key Commercial Data) | Sn |
| Number of positions (Key Commercial Data) | 1 |
| Conductor cross section AWG max. (General) | 12 |
| Conductor cross section AWG min. (General) | 24 |
| Rated voltage (II/2) (Key Commercial Data) | 1000 V |
| Nominal cross section (Key Commercial Data) | 2.5 mm² |
| Rated voltage (III/2) (Key Commercial Data) | 630 V |
| Rated voltage (III/3) (Key Commercial Data) | 500 V |
| Tightening torque max (Key Commercial Data) | 0.6 Nm |
| Tightening torque, min (Key Commercial Data) | 0.5 Nm |
| eCl@ss 4.0 (Environmental Product Compliance) | 27141109 |
| eCl@ss 4.1 (Environmental Product Compliance) | 27141109 |
| eCl@ss 5.0 (Environmental Product Compliance) | 27141190 |
| eCl@ss 5.1 (Environmental Product Compliance) | 27141190 |
| eCl@ss 6.0 (Environmental Product Compliance) | 27261101 |
| eCl@ss 7.0 (Environmental Product Compliance) | 27440401 |
| eCl@ss 8.0 (Environmental Product Compliance) | 27440401 |
| eCl@ss 9.0 (Environmental Product Compliance) | 27440401 |
| Internal cylindrical gage (Key Commercial Data) | A3 |
| Rated surge voltage (II/2) (Key Commercial Data) | 6 kV |
| Rated surge voltage (III/2) (Key Commercial Data) | 6 kV |
| Rated surge voltage (III/3) (Key Commercial Data) | 6 kV |
| Connection in acc. with standard (Connection data) | EN-VDE |
| Connection in acc. with standard (Key Commercial Data) | EN-VDE |
| Weight per Piece (excluding packing) (Your advantages) | 4.040 g |
| 2 conductors with same cross section, solid max. (General) | 1.5 mm² |
| 2 conductors with same cross section, solid min. (General) | 0.2 mm² |
| 2 conductors with same cross section, stranded max. (General) | 1 mm² |
| 2 conductors with same cross section, stranded min. (General) | 0.2 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max. (General) | 0.5 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min. (General) | 0.25 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max. (General) | 1 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min. (General) | 0.5 mm² |
Product Description
Terminal block for printed circuit board, nominal current: 24 A, nominal voltage (III/2): 630 V, nominal cross-section: 2.5 mm², number of potentials: 1, number of rows: 1, number of poles per row: 1,
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
PCB terminal block, nominal current: 24 A, nom. voltage: 630 V, pitch: 7.5 mm, number of positions: 1, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: black
