In Stock Hot Product
GE30I15-P1J
GE30I15-P1J MEANWELL AC-DC Wall mount adaptor, Output 15VDC / 2A, Interchangeable AC plugs are not included ..
$0.00USD
4633 in stock
Key Specifications
Name (Details):GE30I15-P1J
Format (Details):Wall
Series (Details):GE30 (Main Body)
Approvals (Details):CCC, CE, RCM, UL
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name (Details) | GE30I15-P1J |
| Format (Details) | Wall |
| Series (Details) | GE30 (Main Body) |
| Approvals (Details) | CCC, CE, RCM, UL |
| Power (W) (Details) | 30,00 |
| Subformato (Details) | Plug AC Interchangeable |
| Width (mm) (Details) | Forty three |
| Height (mm) (Details) | 40.5 |
| AC input Max (Details) | 264,00 |
| AC input Min (Details) | 90,00 |
| Applications (Details) | Industrial, Telecommunications |
| Manufacturer (Details) | MEAN WELL |
| Product type (Details) | Power supply AC/DC |
| Isolation (V) (Details) | 4.242,00 |
| Output voltage (Details) | 15,00 |
| Peak Power (W) (Details) | Thirty |
| Input connector (Details) | Plug-in |
| Input frequency (Details) | 50 Hz, 60 Hz |
| Long/Background (Details) | Eighty one |
| Long Description (Details) | Wall adapter with input plug interchangeable.Feeder for connection to a wall outlet.Range of universal Input90-264Vac47-63Hz.Output voltage15vdc.Output intensity2A. Range of output current 0-2A according to demand load.Power:30W.Efficiency typical:86%.Class ll without the taking of land.Consumption without load<0,075 W.Conestor type output Jack 5.5 x 2.1 x 11mm. (Outer diameter, inner and length). Center positive.Led indicator of operation.Working temperature: from-10up+50 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:81 x 43 x 50.2 years of warranty.Manufacturer: MEAN WELL.The series GE these sources are switched in the format of a wall with the input connectors to be interchangeable. The plug connection to the network may change, this allows us to use them in different countries by connecting directly to the network jack local.The series GE30 have a low consumption without load, only 0,0075 W and comply with the latest requirements of energy efficiency.The pin network are not included. You can purchase it separately. The references are:AC plug-US plug to USA).AC plug-EU connector (for Europe).AC plug-AU (connector for Australia)AC plug-UK plug for Uk)AC plug-MIX (kit that includes all the input connectors). |
| Output connector (Details) | P1J Tunnig Fork 5.5 x 2.1 x 11. C+ |
| Type of Entry CA (Details) | Single-phase |
| Warranty (Years) (Details) | 2,00 |
| Country of Origin (Details) | Taiwan |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Wall adapter with input plug interchangeable.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
