In Stock Hot Product
FUSE 10,3X85 20A PV
FUSE 10,3X85 20A PV 3062773 PHOENIX CONTACT Fuse
$11.46USD
904 in stock
Key Specifications
GTIN:4046356657266
Orderkey:3062773
Catalog page:Page 467 (C-1-2017)
Packing unit:10 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356657266 |
| Orderkey | 3062773 |
| Catalog page | Page 467 (C-1-2017) |
| Packing unit | 10 pc |
| Length (General) | 85 mm |
| Country of origin | SI (Slovenia) |
| Fuse (Dimensions) | Midget/10.3 x 85 |
| Diameter (General) | 10.3 mm |
| Custom tariff number | 85351000 |
| Minimum order quantity | 10 pc |
| Color (Key Commercial Data) | white |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Nominal current IN (Dimensions) | 20 A |
| Nominal voltage UN (Dimensions) | 1200 V DC |
| Weight per Piece (excluding packing) | 15.940 g |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Connection in acc. with standard (General) | IEC 60269-6 |
| Connection in acc. with standard (Dimensions) | IEC 60269-6 |
| Flammability rating according to UL 94 (General) | V0 |
| Flammability rating according to UL 94 (Key Commercial Data) | V0 |
Product Description
Fuse, 10.3 mm x 85 mm, up to 1500 V DC, gPV feature
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
