FRONT-MSTB 2,5/16-STF-5,08 BU
FRONT-MSTB 2,5/16-STF-5,08 BU 1704588 PHOENIX CONTACT Plug-in part, rated current: 12 A, number of poles: 16..
$0.00USD
3125 in stock
Key Specifications
UNSPSC 11 (ETIM):39121409
ETIM 3.0 (eCl@ss):EC001121
ETIM 4.0 (eCl@ss):EC002638
ETIM 5.0 (eCl@ss):EC002638
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| UNSPSC 11 (ETIM) | 39121409 |
| ETIM 3.0 (eCl@ss) | EC001121 |
| ETIM 4.0 (eCl@ss) | EC002638 |
| ETIM 5.0 (eCl@ss) | EC002638 |
| ETIM 6.0 (eCl@ss) | EC002638 |
| (Connection data) | CSA |
| UNSPSC 13.2 (ETIM) | 39121409 |
| UNSPSC 6.01 (ETIM) | 30211810 |
| UNSPSC 12.01 (ETIM) | 39121409 |
| UNSPSC 7.0901 (ETIM) | 39121409 |
| GTIN (Your advantages) | 4046356729284 |
| Orderkey (Your advantages) | 1704588 |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Packing unit (Your advantages) | 1 |
| Type of contact (Key Commercial Data) | Female connector |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Custom tariff number (Your advantages) | 85366990 |
| Connection method (Key Commercial Data) | Front screw connection |
| Range of articles (Key Commercial Data) | FRONT-MSTB 2,5/..-STF |
| Nominal current IN (Key Commercial Data) | 12 A |
| Maximum AWG according to UL/CUL (General) | 12 |
| Minimum AWG according to UL/CUL (General) | 30 |
| Number of positions (Key Commercial Data) | 16 |
| Conductor cross section AWG max. (General) | 12 |
| Conductor cross section AWG min. (General) | 24 |
| Nominal cross section (Key Commercial Data) | 2.5 mm² |
| Rated voltage (III/3) (Key Commercial Data) | 250 V |
| Conductor cross section solid max. (General) | 2.5 mm² |
| Conductor cross section solid min. (General) | 0.34 mm² |
| eCl@ss 4.0 (Environmental Product Compliance) | 272607xx |
| eCl@ss 4.1 (Environmental Product Compliance) | 27260701 |
| eCl@ss 5.0 (Environmental Product Compliance) | 27260701 |
| eCl@ss 5.1 (Environmental Product Compliance) | 27141190 |
| eCl@ss 6.0 (Environmental Product Compliance) | 27260704 |
| eCl@ss 7.0 (Environmental Product Compliance) | 27440402 |
| eCl@ss 8.0 (Environmental Product Compliance) | 27440309 |
| eCl@ss 9.0 (Environmental Product Compliance) | 27440309 |
| Conductor cross section flexible max. (General) | 2.5 mm² |
| Conductor cross section flexible min. (General) | 0.2 mm² |
| Connection in acc. with standard (Connection data) | EN-VDE |
| Connection in acc. with standard (Key Commercial Data) | EN-VDE |
| 2 conductors with same cross section, solid max. (General) | 1.5 mm² |
| 2 conductors with same cross section, solid min. (General) | 0.2 mm² |
| 2 conductors with same cross section, stranded max. (General) | 1.5 mm² |
| 2 conductors with same cross section, stranded min. (General) | 0.2 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve max. (General) | 2.5 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. (General) | 0.25 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. (General) | 2.5 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve min. (General) | 0.25 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max. (General) | 1 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min. (General) | 0.25 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max. (General) | 1 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min. (General) | 0.5 mm² |
Product Description
Connector for printed circuit board, nominal section: 2.5 mm², color: blue, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of potentials: 16,
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Plug component, nominal current: 12 A, number of positions: 16, pitch: 5.08 mm, connection method: Front screw connection, color: blue, contact surface: Tin
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
