FRONT 2,5-V/SA10/ 3
FRONT 2,5-V/SA10/ 3 1704897 PHOENIX CONTACT PCB terminal block, Nominal current: 24 A, Nom. voltage: 400 V, ..
$3.73USD
2711 in stock
Key Specifications
Pitch:5.00 mm
Height:31 mm
Length:18.5 mm
Dimension a:10 mm
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Pitch | 5.00 mm |
| Height | 31 mm |
| Length | 18.5 mm |
| Dimension a | 10 mm |
| Pin spacing | 10 mm |
| Screw thread | M2,5 |
| Hole diameter | 1.2 mm |
| Pin dimensions | 0,8 x 0,8 mm |
| Stripping length | 9 mm |
| Range of articles | FRONT 2,5-V/SA10 |
| Nominal current IN | 24 A |
| Solder pin surface | Sn |
| Insulating material | PA |
| Number of positions | 3 |
| Maximum load current | 17.5 A |
| Rated voltage (II/2) | 630 V |
| Constructional height | 20 mm |
| Nominal cross section | 2.5 mm² |
| Rated voltage (III/2) | 400 V |
| Rated voltage (III/3) | 250 V |
| Tightening torque max | 0.5 Nm |
| Tightening torque, min | 0.4 Nm |
| Length of the solder pin | 3.5 mm |
| Insulating material group | I |
| Internal cylindrical gage | A3 |
| Rated surge voltage (II/2) | 4 kV |
| Rated surge voltage (III/2) | 4 kV |
| Rated surge voltage (III/3) | 4 kV |
| Conductor cross section AWG max. | 14 |
| Conductor cross section AWG min. | 24 |
| Connection in acc. with standard | EN-VDE |
| Conductor cross section solid max. | 2.5 mm² |
| Conductor cross section solid min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Flammability rating according to UL 94 | V0 |
| 2 conductors with same cross section, solid max. | 0.75 mm² |
| 2 conductors with same cross section, solid min. | 0.2 mm² |
| 2 conductors with same cross section, stranded max. | 0.75 mm² |
| 2 conductors with same cross section, stranded min. | 0.2 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve max. | 1.5 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. | 0.25 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. | 1.5 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve min. | 0.25 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max. | 0.34 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min. | 0.25 mm² |
Product Description
Terminal block for printed circuit board, nominal current: 24 A, nominal voltage (III/2): 400 V, nominal cross-section: 2.5 mm², number of potentials: 3, number of rows: 1, number of poles per row: 3,
