FQI8/BP-0A
FQI8/BP-0A MICRO DETECTORS Photoelectric sensor Axial diffuse 1000 mm, adjustment PNP NO +NC plastic 2m cable
$0.00USD
4216 in stock
Key Specifications
Weight:40g
Emission:Infrared (880 nm)
Approvals:CE,
Dimensions:M18 x 1/L=51,2mm
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 40g |
| Emission | Infrared (880 nm) |
| Approvals | CE, |
| Dimensions | M18 x 1/L=51,2mm |
| Connections | 2m PVC cable |
| Output type | PNP |
| Load current | ≤50mA |
| LED indicators | Yellow (Lon) or output status Lo/Do |
| Optic position | Axial |
| Leakage current | ≤10μA |
| Output Function | NO+NC |
| Repeat Accuracy | 5% |
| Housing Material | PBT |
| EMC compatibility | EN 60947-5-2 |
| Operating Voltage | 10-30Vdc |
| Tightening torque | 1Nm |
| Function Principle | Diffuse reflection |
| Max ripple content | 10% |
| Output voltage drop | 2V max. IL =50 mA |
| Switching frequency | 250Hz |
| Thermal drift of Sr | ≤10% Sr |
| Active Head Material | PC |
| Degree of protection | IP67 |
| Supplied Accessories | nuts M18 x 1, cacciavite |
| Operating temperature | - 25°C…+ 70° C (Without freeze) |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| No-Load supply current | ≤30mA |
| Sensitivity adjustment | Trimmer |
| Nominal sensing distance | 1200mm white target90% Kodak 400x400mm |
| Short-circuit protection | Short circuit (autoreset), Overvoltage |
| Reverse Polarity Protection | Polarity inversal, Inpulsive voltage |
| Interference to external light | 5000lux (incandescent lamp), 10000lux (sunlight) |
| Time delay before availability | ≤200ms |
Product Description
FQI8/BP-0A Photoelectric sensor Axial Diffuse 1000 mm adj.PNP NO +NCplast. 2m cable
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
