In Stock Hot Product
FPSI440/1000
FPSi440/1000 604381 GENERAL ELECTRIC Residual current circuit breaker FP Si 4P 40A 1000mA
$0.00USD
3484 in stock
Key Specifications
Type:Type ASi
Poles:4P
Range:FP
Serie:Series ASi
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Type ASi |
| Poles | 4P |
| Range | FP |
| Serie | Series ASi |
| Series | Residual current circuit breaker |
| Approvals | KEMA, CEBEC, CE |
| Frequency | 50 - 60 Hz |
| Nominal current | Im = 500 A |
| Rated current In | 40 A |
| Residual current | 1000 mA |
| Standard packing | 3 |
| Number of modules | 1 |
| Nominal current Un | 230-400 Vac |
| Ambient temperature | -25°C / 40°C |
| ETIM 5.0 (DIMENSIONS) | EC000003 |
| ETIM 6.0 (DIMENSIONS) | EC000003 |
| Minimum servicevoltage | 180 V |
| Short circuit capacity | Inc = 10000A at 230V/400V |
| Electrical service life | 20000/10000 |
| Weight (SPECIFICATIONS) | 0.385 kg |
| Nuisance tripping resistance | 5000 A 8/20 µs-200 A 0.5 µs-100 kHz |
| Short circuit capacity / norm | fuse 80A gG |
| Short circuit capacity EP30/EP60/EP100 | 6000/10000 A |
| Terminal capacity flexible/rigid cable | 35-50 mm² |
| Differential making and breaking capacity | I(Δ)m = 500 A |
| Tropicalisation according to IEC 60068-2-28/2-30 | 95%RV at 55°C |
Product Description
FPSI440/1000
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
