In Stock Hot Product
FPPS263/300
FPPS263/300 678378 GENERAL ELECTRIC Residual current circuit breaker Fixwell S 2P 63A 300mA
$0.00USD
3799 in stock
Key Specifications
Type:Type S
Poles:2P
Range:DOJP Fixwell screwless
Serie:Series S
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Type S |
| Poles | 2P |
| Range | DOJP Fixwell screwless |
| Serie | Series S |
| Series | Residual current circuit breaker Fixwell |
| Approvals | IMQ, KEMA, CEBEC, VDE, CE |
| Frequency | 50 - 60 Hz |
| Nominal current | Im = 500 A |
| Rated current In | 63 A |
| Residual current | 300 mA |
| Standard packing | 6 |
| Number of modules | 2 |
| Selectivity class | 3 |
| Nominal current Un | 230-400 Vac |
| Ambient temperature | -25°C / +50°C |
| ETIM 5.0 (DIMENSIONS) | EC000003 |
| ETIM 6.0 (DIMENSIONS) | EC000003 |
| Minimum servicevoltage | 110 V |
| Short circuit capacity | Inc = 10000A at 240V/415V |
| Electrical service life | 20000/10000 |
| Weight (SPECIFICATIONS) | 0.248 kg |
| Nuisance tripping resistance | 250 A 8/20 µs |
| Short circuit capacity / norm | fuse 80A gG |
| Terminal capacity flexible/rigid cable | 35-50 mm² |
| Differential making and breaking capacity | I(Δ)m >= 10 In |
| Tropicalisation according to IEC 60068-2-28/2-30 | 95%RV at 55°C |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
