FPPA425/100
FPPA425/100 678368 GENERAL ELECTRIC Residual current circuit breaker Fixwell A 4P 25A 100mA
$0.00USD
3844 in stock
Key Specifications
Type:Type A
Poles:4P
Range:DOJP Fixwell screwless
Serie:Series A
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Type A |
| Poles | 4P |
| Range | DOJP Fixwell screwless |
| Serie | Series A |
| Series | Residual current circuit breaker Fixwell |
| Approvals | IMQ, KEMA, CEBEC, VDE, CE |
| Frequency | 50 - 60 Hz |
| Nominal current | Im = 500 A |
| Rated current In | 25 A |
| Residual current | 100 mA |
| Standard packing | 3 |
| Number of modules | 4 |
| Selectivity class | 3 |
| Nominal current Un | 230 / 400 Vac |
| Ambient temperature | -25°C / +50°C |
| ETIM 5.0 (DIMENSIONS) | EC000003 |
| ETIM 6.0 (DIMENSIONS) | EC000003 |
| Minimum servicevoltage | 190 V |
| Short circuit capacity | Inc = 10000A at 240V/415V |
| Electrical service life | 20000/10000 |
| Weight (SPECIFICATIONS) | 0.364 kg |
| Nuisance tripping resistance | 250 A 8/20 µs |
| Short circuit capacity / norm | fuse 80A gG |
| Terminal capacity flexible/rigid cable | 35-50 mm² |
| Differential making and breaking capacity | I(Δ)m >= 500 A |
| Tropicalisation according to IEC 60068-2-28/2-30 | 95%RV at 55°C |
