FPF263/030
FPF 2 63/030 565375 GENERAL ELECTRIC Residual current circuit breaker FP F 2P 63A 30mA
$0.00USD
3347 in stock
Key Specifications
Status:Active
ETIM 5.0 (DIMENSIONS):EC000003
ETIM 6.0 (DIMENSIONS):EC000003
Weight (SPECIFICATIONS):0.22 kg
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Status | Active |
| ETIM 5.0 (DIMENSIONS) | EC000003 |
| ETIM 6.0 (DIMENSIONS) | EC000003 |
| Weight (SPECIFICATIONS) | 0.22 kg |
| (ORDER/DELIVERY STATUS) | IP20 |
| Type (ORDER/DELIVERY STATUS) | Type F |
| AC/DC (ORDER/DELIVERY STATUS) | AC |
| Poles (ORDER/DELIVERY STATUS) | 2P |
| Range (ORDER/DELIVERY STATUS) | FPF |
| Series (ORDER/DELIVERY STATUS) | Residual current circuit breaker |
| Approvals (ORDER/DELIVERY STATUS) | CE |
| Frequency (ORDER/DELIVERY STATUS) | 50/60 Hz |
| Approval/norm (ORDER/DELIVERY STATUS) | EN/IEC 61008-1 |
| Cable section (ORDER/DELIVERY STATUS) | Top terminal: 1,5-35 mm²/Bottom terminal: 1,5-50 mm² |
| Shock voltage (ORDER/DELIVERY STATUS) | 6 |
| Operating time (ORDER/DELIVERY STATUS) | <300ms |
| Minimal tension (ORDER/DELIVERY STATUS) | 176 |
| Rated current In (ORDER/DELIVERY STATUS) | 63 A |
| Residual current (ORDER/DELIVERY STATUS) | 30 mA |
| Standard packing (ORDER/DELIVERY STATUS) | 1/6 |
| Number of modules (ORDER/DELIVERY STATUS) | 2 |
| Selectivity class (ORDER/DELIVERY STATUS) | 3 |
| Nominal current Un (ORDER/DELIVERY STATUS) | 240 VAC |
| Ambient temperature (ORDER/DELIVERY STATUS) | -25°C / +40°C |
| Storage temperature (ORDER/DELIVERY STATUS) | -25°C / +70°C |
| Operating temperature (ORDER/DELIVERY STATUS) | -25ºC / +40ºC |
| Minimum servicevoltage (ORDER/DELIVERY STATUS) | 176 V |
| Electrical service life (ORDER/DELIVERY STATUS) | 10000 |
| Nuisance tripping resistance (ORDER/DELIVERY STATUS) | 3000A 8/20 msc |
| Terminal capacity flexible/rigid cable (ORDER/DELIVERY STATUS) | 1.5-50 mm² |
| Differential making and breaking capacity (ORDER/DELIVERY STATUS) | I(Δ)m = 10In |
| Tropicalisation according to IEC 60068-2-28/2-30 (ORDER/DELIVERY STATUS) | 95%RV at 55°C |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
