FKCOW 2,5/ 2-ST-5,08
FKCOW 2,5/ 2-ST-5,08 1860549 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
4808 in stock
Key Specifications
GTIN:4055626123295
Note:Made to Order (non-returnable)
Orderkey:1860549
Packing unit:250 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4055626123295 |
| Note | Made to Order (non-returnable) |
| Orderkey | 1860549 |
| Packing unit | 250 pc |
| Country of origin | SK (Slovakia) |
| (Connection data) | Cross section: 2.5 mm²; Length: 8 mm ... 10 mm |
| Custom tariff number | 85366990 |
| (Ambient conditions) | No hazardous substances above threshold values |
| Pitch (Key Commercial Data) | 5.08 mm |
| Stripping length (Dimensions) | 10 mm |
| Range of articles (Dimensions) | FKCOW 2,5/..-ST |
| China RoHS (Ambient conditions) | Environmentally friendly use period: unlimited = EFUP-e |
| Nominal current IN (Dimensions) | 12 A |
| Nominal voltage UN (Dimensions) | 250 V |
| Insulating material (Dimensions) | PA |
| Number of positions (Dimensions) | 2 |
| Dimension a (Key Commercial Data) | 5.08 mm |
| Rated voltage (II/2) (Dimensions) | 630 V |
| Width [ w ] (Key Commercial Data) | 10.03 mm |
| Height [ h ] (Key Commercial Data) | 16.8 mm |
| Length [ l ] (Key Commercial Data) | 23.7 mm |
| Nominal cross section (Dimensions) | 2.5 mm² |
| Rated voltage (III/2) (Dimensions) | 320 V |
| Weight per Piece (excluding packing) | 2.220 g |
| Insulating material group (Dimensions) | I |
| Rated surge voltage (II/2) (Dimensions) | 4 kV |
| Rated surge voltage (III/2) (Dimensions) | 4 kV |
| Rated surge voltage (III/3) (Dimensions) | 4 kV |
| Conductor cross section AWG max. (General) | 12 |
| Conductor cross section AWG min. (General) | 24 |
| Conductor cross section solid max. (General) | 2.5 mm² |
| Conductor cross section solid min. (General) | 0.2 mm² |
| Connection in acc. with standard (Dimensions) | EN-VDE |
| Recommended crimping pliers (Connection data) | 1212034 CRIMPFOX 6 |
| Conductor cross section flexible max. (General) | 2.5 mm² |
| Conductor cross section flexible min. (General) | 0.2 mm² |
| Flammability rating according to UL 94 (Dimensions) | V0 |
| Ambient temperature (assembly) (Standards and Regulations) | -5 °C ... 100 °C |
| Ambient temperature (operation) (Standards and Regulations) | -40 °C (dependent on the derating curve) |
| Connection in acc. with standard (Specifications for ferrules) | EN-VDE |
| Ambient temperature (storage/transport) (Standards and Regulations) | -40 °C ... 70 °C |
| Flammability rating according to UL 94 (Specifications for ferrules) | V0 |
| Ferrules without insulating collar, according to DIN 46228‑1 (Connection data) | Cross section: 0.25 mm²; Length: 7 mm |
| Conductor cross section flexible, with ferrule with plastic sleeve max. (General) | 2.5 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. (General) | 0.14 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. (General) | 2.5 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve min. (General) | 0.25 mm² |
Product Description
Connector for printed circuit board, nominal section: 2.5 mm², color: green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of potentials: 2,
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
