FKC12-48S05W
FKC12-48S05W MEANWELL DC-DC converter for PCB mount, Input: 18-75VDC. Output: 5,1VDC. 2400mA. Power: 12W. I/..
$0.00USD
4158 in stock
Key Specifications
Name:FKC12-48S05W
Format:For Printed Circuit
Series:FKC12W
Approvals:CE, UL
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | FKC12-48S05W |
| Format | For Printed Circuit |
| Series | FKC12W |
| Approvals | CE, UL |
| Power (W) | 12,00 |
| Subformato | DIP |
| Width (mm) | 20.3 |
| Height (mm) | 10.2 |
| Input range | 4:1 |
| Applications | Automation of Buildings, Industrial, Instrumentation, Telecommunications |
| DC input Max | 75,00 |
| DC input Min | 18,00 |
| Manufacturer | P-DUKE |
| Product type | Dc/DC converters |
| Isolation (V) | 1.600,00 |
| Output voltage | 5,10 |
| Peak Power (W) | Twelve |
| Range DC Input | 18, 19, 20,4, 21, 21,6, 22,5, 24, 25,2, 26,4, 28, 28,8, 30, 31,2, 32, 32,4, 33,6, 35, 36, 36,4, 38,4, 40, 43, 46,8, 50, 50,4, 52, 56, 60, 62,4, 64,4, 67,2, 72, 75 |
| Input connector | Pin |
| Long/Background | 31.8 |
| Long Description | Dc/DC converter to the printed circuit board in format DIP, with isolation of 1600Vcc, regulated.Metallic box.FormatDIPfor soldering on printed circuit boards.Input range18-75Vcc.Output voltage5,1 Vdc.Output intensity2400mA.Power:12W.Isolation input-output 1600Vcc.Efficiency typical: 87%.Low noise and ripple 85mVp-p.Without the need of minimum load on the output.Working temperature: from-40up+100 ° C. See the curve of drift according to the temperature in the technical data sheet.Max temperature box:+100 ° C.Dimensions (Length x Width x Height) [mm]:31,8 x 20,3 x 10,2.3 years of warranty.Manufacturer: P-DUKE.The converters of the series FKC12W have a wide input range 4:1 and an isolation between input and output of 1600Vcc. Do not have requirements of minimum load on the output and are protected against overloads and short-circuits. Its metal case improved behavior of temperature at the same time improving the behavior EMI.CE certified and UL listed. |
| Output connector | Pin |
| Warranty (Years) | 3,00 |
| Country of Origin | Taiwan |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Dc/DC converter to the printed circuit board in format DIP, with isolation of 1600Vcc, regulated.
