FGRL3NN0630/7
FGRL3NN0630-7 436722 GENERAL ELECTRIC FG630-RatingPlug 3P 3trips SMR2 Line only 630A 630A sensor
$0.00USD
4761 in stock
Key Specifications
Status:Active
ETIM 5.0 (DIMENSIONS):EC000617
ETIM 6.0 (DIMENSIONS):EC000617
Weight (SPECIFICATIONS):0.05 kg
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Status | Active |
| ETIM 5.0 (DIMENSIONS) | EC000617 |
| ETIM 6.0 (DIMENSIONS) | EC000617 |
| Weight (SPECIFICATIONS) | 0.05 kg |
| Trips (ORDER/DELIVERY STATUS) | 3 trips |
| In (A) (ORDER/DELIVERY STATUS) | 630 A |
| Ir (A) (ORDER/DELIVERY STATUS) | 400-630 A |
| Series (ORDER/DELIVERY STATUS) | Rating plug |
| Trip Unit (ORDER/DELIVERY STATUS) | Line & Generator protection (SMR2) |
| Frame type (ORDER/DELIVERY STATUS) | G frame (400A/630A) |
| Number of poles (ORDER/DELIVERY STATUS) | 3P |
| Rating frame (A) (ORDER/DELIVERY STATUS) | 630 A |
| Standard packing (ORDER/DELIVERY STATUS) | 1 |
| For Trip Unit- In (A) (ORDER/DELIVERY STATUS) | 630 A |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Specifically designed for line protection with a setting range of 0.64 to 1 x the plug rating over 16 setpoints. The settings on the devices are in current values and thus allow for ease of setting. Each trip unit size can be equipped with one of two adjustable rating plug ratings. For 4 pole trip units the rating plugs exist in 3 and 4 pole protected versions with a choice in neutral rating between 50 or 100% of the phase value.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
