FED40-48D15W
FED40-48D15W MEANWELL DC-DC converter for PCB mount, Input: 18-75VDC. Dual Output: -15 / +15VDC. Power: 40W...
$0.00USD
3025 in stock
Key Specifications
Name:FED40-48D15W
Format:For Printed Circuit
Series:FED40W
Output 1:-15
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | FED40-48D15W |
| Format | For Printed Circuit |
| Series | FED40W |
| Output 1 | -15 |
| Output 2 | +15 |
| Approvals | CE, UL |
| Power (W) | 40,00 |
| Subformato | DIP |
| Width (mm) | 25.4 |
| Height (mm) | 10.2 |
| Input range | 4:1 |
| Applications | Building automation, Rail, Industrial, Instrumentation, Telecommunications |
| DC input Max | 75,00 |
| DC input Min | 18,00 |
| Manufacturer | P-DUKE |
| Product type | Dc/DC converters |
| Isolation (V) | 1.600,00 |
| Peak Power (W) | Forty |
| Range DC Input | 18, 19, 20,4, 21, 21,6, 22,5, 24, 25,2, 26,4, 28, 28,8, 30, 31,2, 32, 32,4, 33,6, 35, 36, 36,4, 38,4, 40, 43, 46,8, 50, 50,4, 52, 56, 60, 62,4, 64,4, 67,2, 72, 75 |
| Input connector | Pin |
| Long/Background | 50.8 |
| Long Description | Dc/DC converter to the printed circuit board in format DIP, with isolation of 1600Vcc, regulated.Plastic box.FormatDIPfor soldering on printed circuit boards.Input range18-75Vcc.Outputs:-15vdc:Without the need of minimum load.Maximum output current1333mA.+15vdc:Without the need of minimum load.Maximum output current1333mA.Power:40W.Isolation input-output 1600Vcc.Efficiency-typical: 90%.Low noise and ripple 100mVp-p.Minimum load of 10%. The no-load operation will not damage the converter but will not meet all specifications.Working temperature: from-40up+105ºC. See the curve of drift according to the temperature in the technical data sheet.Dimensions (Length x Width x Height) [mm]:50.8 x 25.4 x 10.2.3 years of warranty.Manufacturer: P-DUKE.The converters of the series FED40W have a wide input range 4:1 and an isolation between input and output of 1600Vcc. Are protected against overloads and short-circuits.CE certificates and US. |
| Output connector | Pin |
| Warranty (Years) | 3,00 |
| Country of Origin | Taiwan |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Dc/DC converter to the printed circuit board in format DIP, with isolation of 1600Vcc, regulated.
