FED30-24S05
FED30-24S05 MEANWELL DC-DC converter for PCB mount, Input: 18-36VDC. Output: 5VDC. 6A. Power: 30W. I/O isola..
$0.00USD
3083 in stock
Key Specifications
Name:FED30-24S05
Format:For Printed Circuit
Series:FED30
Approvals:CE, UL
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | FED30-24S05 |
| Format | For Printed Circuit |
| Series | FED30 |
| Approvals | CE, UL |
| Power (W) | 30,00 |
| Subformato | DIP |
| Width (mm) | 25.4 |
| Height (mm) | 10.2 |
| Input range | 2:1 |
| Applications | Building automation, Industrial, Telecommunications |
| DC input Max | 36,00 |
| DC input Min | 18,00 |
| Manufacturer | P-DUKE |
| Product type | Dc/DC converters |
| Isolation (V) | 1.600,00 |
| Output voltage | 5,00 |
| Peak Power (W) | Thirty |
| Range DC Input | 18, 19, 20,4, 21, 21,6, 22,5, 24, 25,2, 26,4, 28, 28,8, 30, 31,2, 32, 32,4, 33,6, 35, 36 |
| Input connector | Pin |
| Long/Background | 50.8 |
| Long Description | Dc/DC converter to the printed circuit board in format DIP, with isolation of 1600Vcc, regulated.Box of metal.FormatDIPfor soldering on printed circuit boards.Input range18-36Vcc.Output voltage5vdc.Output intensity75mA.Power:30W.Isolation input-output 1600Vcc.Efficiency-typical: 90%.Low noise and ripple 100mVp-p.Minimum load of 10%. The no-load operation will not damage the converter but will not meet all specifications.Working temperature: from-40up+85 ° C. See the curve of drift according to the temperature in the technical data sheet.Dimensions (Length x Width x Height) [mm]:50.8 x 25.4 x 10.2.3 years of warranty.Manufacturer: P-DUKE.The converters of the series FED30 have a wide input range 2:1 and an isolation between input and output of 1600Vcc. Are protected against overloads and short-circuits.CE certificates and US. |
| Output connector | Pin |
| Warranty (Years) | 3,00 |
| Country of Origin | Taiwan |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Dc/DC converter to the printed circuit board in format DIP, with isolation of 1600Vcc, regulated.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
