FD-L10V
FD-L10V PANASONIC Vacuum-resistant optical fiber, diffuse reflection, rectangular head 19x5x27mm, temperatur..
$0.00USD
4702 in stock
Key Specifications
Item:Specifications
Details:Vacuum-resistant Fiber
Product:Convergent Reflective type Fiber
Free-cut:Not available
Supplier Information
PANASONIC
Products: 4316
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Item | Specifications |
| Details | Vacuum-resistant Fiber |
| Product | Convergent Reflective type Fiber |
| Free-cut | Not available |
| Fiber type | Glass substrate detection |
| Application | Vacuum-resistant |
| Part Number | FD-L10V |
| Semi-custom | Fiber length change |
| With sleeve | No |
| Product name | One-Touch Connection System Vacuum-resistant Fibers |
| Sensing mode | Convergent Reflective type |
| Mounting lens | Not available |
| Beam direction | Top-view |
| Product Number | FD-L10V |
| Fiber head length | W19 x H5 x D27 mm |
| Fiber cable length | 3m |
| Sensing range（STD） | 0 to 8 mm 0 to 0.315 in (FX-500 series) |
| Sensing range（FAST） | 0 to 5.5 mm 0.217 in (FX-500 series) |
| Sensing range（H-SP） | 1.5 to 3 mm 0.059 to 0.118 in (FX-500 series) |
| Sensing range（HYPR） | 0 to 18 mm 0 to 0.709 in (FX-500 series) |
| Sensing range（LONG） | 0 to 10 mm 0 to 0.394 in (FX-500 series) |
| Sensing range（U-LG） | 0 to 12 mm 0 to 0.472 in (FX-500 series) |
| Allowable bending radius | R25mm |
| Mounting protective tube | Not available |
| Sensing range（範囲） | 01##0-50mm |
| Fiber type（レンジ指定） | Particular use |
| Allowable bending radius（レンジ指定） | 08##R25mm |
| Environmental resistance : Ambient temperature MAX | 300 degrees |
| Environmental resistance : Ambient temperature MIN | -30 degrees |
| Environmental resistance : Ambient temperature MAX（レンジ指定） | 06##201-300 degrees |
| Environmental resistance : Ambient temperature MIN（レンジ指定） | 04##-30 degrees |
Product Description
FD-L10V_Convergent Reflective type Fiber_One-Touch Connection System Vacuum-resistant Fibers_Vacuum-resistant Fiber
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
