In Stock Hot Product
FAI9/BN-0E
FAI9/BN-0E MICRO DETECTORS Photoelectric sensor Axial diffuse 1000 mm NPN NO+NC plastic plug M12
$0.00USD
3563 in stock
Key Specifications
Weight:30g
Emission:Infrared (880 nm)
Dimensions:M18 x 1 /L =81,6 mm
Connections:Connector M12 4 pins
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 30g |
| Emission | Infrared (880 nm) |
| Dimensions | M18 x 1 /L =81,6 mm |
| Connections | Connector M12 4 pins |
| Output type | NPN |
| Load current | ≤100mA |
| Exit function | NA+NC |
| Nominal range | 1000mm object white 90% Kodak 400x400mm |
| Position lens | Axial |
| Repeatability | 5% |
| Thermal drift | ≤10% Sr |
| body material | PBT |
| Certifications | CE, cULus |
| LED indicators | Yellow (state of output) |
| Supply voltage | 10-30Vdc |
| Leakage current | ≤10µA |
| Tightening torque | 1Nm |
| Shock and vibration | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| Switching frequency | 250Hz |
| Accessories included | 1 x nut M18, screwdriver |
| Degree of protection | IP67 |
| Operating temperature | - 25°C...+ 70° C (without condensation) |
| Principle of operation | Direct reflection |
| Sensitivity adjustment | Not |
| Maximum residual ripple | 10% |
| Protection short circuit | short circuit (auto reset), overvoltage |
| Delay to the availability | ≤200ms |
| Immunity to ambient light | 3000lux (incandescent lamp), 10000lux (sunlight) |
| Voltage drop to the output | 2V max. IL =100 mA |
| Protection polarity reversal | polarity reversal, impulse surge |
| Electromagnetic compatibility | According to en 60947-5-2 |
| Material of the active surface | PC |
| Absorption of current in the vacuum | ≤30mA |
Product Description
FAI9/BN-0E Photoelectric sensor Axial Diffuse 1000 mm NPN NO+NC plast. conn. M12
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
