In Stock Hot Product
EVSG-ORD 25/B
EVSG-ORD 25/B 10064645 WISKA Black round cap RAL 9005, PA IP68 thread M25
$0.00USD
4007 in stock
Key Specifications
Lead (Features):1,5
Type (Features):EVSG-ORD 25
Material (Features):Polyamide, fibre reinforced
Thread type (Features):M
Supplier Information
WISKA
Products: 2869
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Lead (Features) | 1,5 |
| Type (Features) | EVSG-ORD 25 |
| Material (Features) | Polyamide, fibre reinforced |
| Thread type (Features) | M |
| Packing unit (Features) | 100 |
| Product Color (Features) | RAL 9005 |
| Glow wire test (Features) | 650 °C |
| Temp. range max (Features) | 100 °C |
| Temp. range min (Features) | -40 °C |
| Total length TL (Features) | 11,5 mm |
| Protection class (Features) | IP66 / IP68 (5 bar 30 min) |
| Order no. RAL 9005 (Features) | 10064645 |
| ETIM-Classification (Features) | EC000032 |
| External diameter ED (Features) | 30 mm |
| Ø Connection thread D (Features) | 25 |
| Material sealing gasket (Features) | EPDM |
| Length screw-in thread L (Features) | 8 mm |
Product Description
Stop end with mounted O-Ring, polyamide, RAL 9005, M25
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
