EG 45-GL /ABS GN
EG 45-GL /ABS GN 2907185 PHOENIX CONTACT Electronic housing
$0.00USD
3950 in stock
Key Specifications
Type:Lower housing part, with snap-on foot
Width:45 mm
Height:75 mm
Housing type:Component housing
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Lower housing part, with snap-on foot |
| Width | 45 mm |
| Height | 75 mm |
| Housing type | Component housing |
| Product type | Enclosure bottom part |
| Mounting type | DIN rail mounting |
| PCB thickness | 1.4 mm ... 1.8 mm |
| Housing series | EG |
| Product family | EG..-G |
| Color (Housing) | green (RAL 6021) |
| Housing material | ABS |
| Dimensional drawing | |
| Number of positions | 16 |
| Degree of protection | IP20 |
| Thickness of the PCB | 1.4 mm ... 1.8 mm |
| Max. IP code to attain | IP20 |
| Surface characteristics | untreated |
| Max. number of positions | 0) |
| Ventilation openings present | no |
| Ambient temperature (assembly) | -5 °C ... 80 °C |
| Ambient temperature (operation) | -40 °C ... 80 °C (depending on power dissipation) |
| Flammability rating according to UL 94 | HB |
| Ambient temperature (storage/transport) | -40 °C ... 55 °C |
Product Description
Lower part of the housing with ventilation channel and with fixing foot
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
