DRP-480S-48
DRP-480S-48 MEANWELL AC-DC Industrial DIN rail power supply, Output 48VDC / 10A, metal case, EU input only
$0.00USD
4869 in stock
Key Specifications
Fan:Yes
Name:DRP-480S-48
State:Do not Use for New Designs
Format:Din Rail
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Fan | Yes |
| Name | DRP-480S-48 |
| State | Do not Use for New Designs |
| Format | Din Rail |
| Series | DRP-480S |
| Approvals | CE, UL |
| Power (W) | 480,00 |
| Subformato | Narrow |
| Width (mm) | 227.00 |
| Height (mm) | 125.10 |
| AC input Max | 264,00 |
| AC input Min | 180,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 3.000,00 |
| Output voltage | 48,00 |
| Peak Power (W) | Four hundred eighty |
| Input connector | Screw-Type |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 100.00 |
| Long Description | Switching Power supply for DIN Rail.Format to mount on a Din Rail.Range of universal Input180-264vac47-63Hz.Output voltage48vdc.Adjustable by potentiometer (48-55Vcc).Output intensity:10A. Range of output current 0-10A according to demand load.Power:480W.Efficiency:89%, low dissipation.Factor corrector, power0.7 at 230vac.Working temperature: from-20up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Width x Height x depth):227 x 125,2 x 100mm.3 years of warranty.Manufacturer: MEANWELL.The series DRP-480 are power supplies, single phase for Din rail mounting with metal housing and fanless design.Models are for large industrial equipment with PFC function liabilities, as well as input selectable by switch. |
| Output connector | Screw-Type |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Switching Power supply for DIN Rail.
