DRP-480-48
DRP-480-48 MEANWELL AC-DC Industrial DIN rail power supply, Output 48VDC / 10A, metal case
$0.00USD
3842 in stock
Key Specifications
Name:DRP-480-48
State:Do not Use for New Designs
Stock:Yes
Format:Din Rail
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | DRP-480-48 |
| State | Do not Use for New Designs |
| Stock | Yes |
| Format | Din Rail |
| Series | DRP-480 |
| Approvals | CE, UL |
| Power (W) | 480,00 |
| Subformato | Narrow |
| Width (mm) | 227.00 |
| Height (mm) | 125.20 |
| AC input Max | 264,00 |
| AC input Min | 180,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 3.000,00 |
| Output voltage | 48,00 |
| Peak Power (W) | Four hundred eighty |
| Input connector | Screw-Type |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 100.00 |
| Long Description | Switching Power supply for DIN Rail.Format to mount on a Din Rail.Range of universal Input180-264vac47-63Hz.Output voltage48vdc.Adjustable by potentiometer (48-53Vcc).Output intensity:10A. Range of output current 0-10A according to demand load.Power:480W.Efficiency:89%.Factor corrector, power0.7 at 230vac.Working temperature: from-20up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Width x Height x depth):227 x 125,2 x 100mm.3 years of warranty.Manufacturer: MEANWELL.The series DRP-480 are power supplies, single phase for Din rail mounting with metal housing and fanless design.Models are for large industrial equipment with PFC function passive. |
| Output connector | Screw-Type |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Switching Power supply for DIN Rail.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
