DR-75-24
DR-75-24 MEANWELL AC-DC Industrial DIN rail power supply, Output 24VDC / 3.2A, metal case
$0.00USD
3967 in stock
Key Specifications
Name:DR-75-24
State:Do not Use for New Designs
Format:Din Rail
Series:DR-75
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | DR-75-24 |
| State | Do not Use for New Designs |
| Format | Din Rail |
| Series | DR-75 |
| Approvals | CE, UL |
| Power (W) | 76,80 |
| Subformato | Narrow |
| Width (mm) | 55.50 |
| Height (mm) | 125.20 |
| AC input Max | 264,00 |
| AC input Min | 85,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 3.000,00 |
| Output voltage | 24,00 |
| Peak Power (W) | 76.8 |
| Input connector | Screw-Type |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 100.00 |
| Long Description | Switch mode Power supply.Format to mount on a Din Rail.Range of universal Input85-264vac47-63Hz.Output voltage24vdc.Adjustable by potentiometer (24-28Vcc).Output intensity:3.2 ToRange of output current 0-3,2 according To the demand load.Power:76.8 W.Efficiency:80%.Working temperature: from-10up+60 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Width x Height x depth):55,5 x 125,2 x 100mm.3 years of warranty.Manufacturer: MEANWELL.Series DR-75 are power supplies for din rail class II, without grounding, intended for installing in an electrical box housing for applications in building automation or industrial applications. Its format, type ladder is perfectly suited to the electrical boxes. |
| Output connector | Screw-Type |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Switch mode Power supply.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
