DR-4505
DR-4505 MEANWELL AC-DC Industrial DIN rail power supply, Output 5VDC / 5A, plastic case
$0.00USD
4529 in stock
Key Specifications
Name:DR-4505
State:Do not Use for New Designs
Format:Din Rail
Series:DR-45
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name | DR-4505 |
| State | Do not Use for New Designs |
| Format | Din Rail |
| Series | DR-45 |
| Approvals | CE, UL |
| Power (W) | 25,00 |
| Subformato | Narrow |
| Width (mm) | 93.00 |
| Height (mm) | 67.00 |
| AC input Max | 264,00 |
| AC input Min | 85,00 |
| Applications | Industrial, Telecommunications |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Isolation (V) | 3.000,00 |
| Output voltage | 5,00 |
| Peak Power (W) | Twenty five |
| Input connector | Screw-Type |
| Input frequency | 50 Hz, 60 Hz |
| Long/Background | 78.00 |
| Long Description | Switch mode Power supply.Format to mount on a Din Rail.Range of universal Input85-264vac47-63Hz.Output voltage5vdc.Adjustable by potentiometer (4,75-5,5 Vdc).Output intensity:5ARange of output current 0-5A according to demand load.Power:25W.Efficiency:72%.Working temperature: from-10up+50 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Width x Height x depth):93 x 78 x 67mm.3 years of warranty.Manufacturer: MEANWELL.Series DR-45 are power supplies for din rail class I, with ground, designed to install in electrical boxes housing for applications in building automation or industrial applications. Its format is perfectly adapted to the electrical boxes. |
| Output connector | Screw-Type |
| Type of Entry CA | Single-phase |
| Warranty (Years) | 3,00 |
| Country of Origin | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Switch mode Power supply.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
