DPU01L-15
DPU01L-15 MEANWELL DC-DC Converter for PCB mount, Input 4.5-5.5VDC, Dual Output ±15VDC / 0.033A, SIP Through..
$0.00USD
3086 in stock
Key Specifications
Name (Details):DPU01L-15
State (Details):New
Format (Details):For Printed Circuit
Series (Details):SPU01 & DPU01
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name (Details) | DPU01L-15 |
| State (Details) | New |
| Format (Details) | For Printed Circuit |
| Series (Details) | SPU01 & DPU01 |
| Output 1 (Details) | -15 |
| Output 2 (Details) | +15 |
| Approvals (Details) | EC |
| Power (W) (Details) | 1,00 |
| Subformato (Details) | SIP |
| Width (mm) (Details) | 6.1 |
| Height (mm) (Details) | 10.2 |
| Input range (Details) | +/-10% |
| Applications (Details) | Industrial, Instrumentation, Telecommunications |
| DC input Max (Details) | 5,50 |
| DC input Min (Details) | 4,50 |
| Manufacturer (Details) | MEAN WELL |
| Product type (Details) | Dc/DC converters |
| Isolation (V) (Details) | 1.500,00 |
| Peak Power (W) (Details) | One |
| Input connector (Details) | Pin |
| Long/Background (Details) | 19.5 |
| Long Description (Details) | onvertidor DC/DC for printed circuit board in format SIP6, with isolation of 1500Vcc.FormatSIPfor printed circuit boards.Input range4,5-5,5Vcc.Outputs:-15vdc:Without the need of minimum load.Maximum output current33mA.+15vdc:Without the need of minimum load.Maximum output current33mA.Power:1W.Efficiency typical:75%.Low noise and ripple 75mVp-p.Working temperature: from-40up+90 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:Or 19.5 x 6.1 x 10.2.3 years of warranty.Manufacturer: MEAN WELL.The new series DPU01 are converters 1W isolated in the format SIP EN55032 class A without additional components and have a wide range of temperature operation, and isolation between input and output of 1500Vcc. Are protected against overloads and short-circuits.CE certificate. |
| Output connector (Details) | Pin |
| Warranty (Years) (Details) | 3,00 |
| Country of Origin (Details) | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
onvertidor DC/DC for printed circuit board in format SIP6, with isolation of 1500Vcc.
