DPAN02C-12
DPAN02C-12 MEANWELL DC-DC Converter for PCB mount, Input 36-75VDC, Dual Output ±12VDC / 0.083A, SIP Through ..
$0.00USD
4648 in stock
Key Specifications
Name (Details):DPAN02C-12
State (Details):New
Format (Details):For Printed Circuit
Series (Details):DPAN02
Supplier Information
MEANWELL
Products: 6448
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Name (Details) | DPAN02C-12 |
| State (Details) | New |
| Format (Details) | For Printed Circuit |
| Series (Details) | DPAN02 |
| Output 1 (Details) | -12 |
| Output 2 (Details) | +12 |
| Approvals (Details) | EC, EAC |
| Power (W) (Details) | 2,00 |
| Subformato (Details) | SIP |
| Width (mm) (Details) | 9.2 |
| Height (mm) (Details) | 11.1 |
| Input range (Details) | 2:1 |
| Applications (Details) | Industrial, Instrumentation, Telecommunications |
| DC input Max (Details) | 75,00 |
| DC input Min (Details) | 36,00 |
| Manufacturer (Details) | MEAN WELL |
| Product type (Details) | Dc/DC converters |
| Isolation (V) (Details) | 3.000,00 |
| Peak Power (W) (Details) | Two |
| Input connector (Details) | Pin |
| Long/Background (Details) | 21.8 |
| Long Description (Details) | DC/DC converter to the printed circuit board in format SIP8, isolation 1500Vcc. Regulated.FormatSIPfor printed circuit boards.Input range36-75Vcc.Outputs:-12vdc:Without the need of minimum load.Maximum output current83mA.+12vdc:Without the need of minimum load.Maximum output current83mA.Power:2W.Efficiency typical:82%.Low noise and ripple 75mVp-p.Remote Control ON/OF.Minimum load not required.Working temperature: from-40up+90 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:In 19.5 x 9.8 x 12.5.3 years of warranty.Manufacturer: MEAN WELL.The new series SPAN02 are converters 2W isolated in format SIP8. Complies with the EN55032 class A without additional components and have a wide range of temperature operation, and isolation between input and output of 1500Vcc. Are protected against overloads and short-circuits.CE certificate. |
| Output connector (Details) | Pin |
| Warranty (Years) (Details) | 3,00 |
| Country of Origin (Details) | China |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
DC/DC converter to the printed circuit board in format SIP8, isolation 1500Vcc. Regulated.
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
