DOCA463/030
DOCA463/030 607680 GENERAL ELECTRIC DIFF-O-CLICK Residual current devices Series A 4P 4M 63A 30mA
$0.00USD
4427 in stock
Key Specifications
Type:Type A
Poles:4P
Range:Diff-o-Click
Serie:Series A
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Type A |
| Poles | 4P |
| Range | Diff-o-Click |
| Serie | Series A |
| Series | Add-on residential current devices |
| Approvals | IMQ, KEMA, CEBEC, CE |
| Frequency | 50 - 60 Hz |
| Rated current In | 63 A |
| Residual current | 30 mA |
| Standard packing | 1 |
| Number of modules | 4 |
| Nominal current Un | 400 Vac |
| Ambient temperature | -25°C / 40°C |
| ETIM 5.0 (DIMENSIONS) | EC000003 |
| ETIM 6.0 (DIMENSIONS) | EC000003 |
| Minimum servicevoltage | 180 V |
| Electrical service life | 20000/10000 |
| Weight (SPECIFICATIONS) | 0.34 kg |
| Nuisance tripping resistance | 250 A 8/20µs - 200 A 0.5 µs - 100 kHz |
| Differential capacity EP30/EP60/EP100 | 6000/10000 A |
| Short circuit capacity EP30/EP60/EP100 | 6000/10000 A |
| Terminal capacity flexible/rigid cable | 25-35 mm² |
| Tropicalisation according to IEC 60068-2-28/2-30 | 95%RV at 55°C |
Product Description
DOCA463/030
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
