In Stock Hot Product
DGR/DN-3AEA
DGR/DN-3AEA MICRO DETECTORS Photoelectric sensor Receiver NPN-DOn D10mm clip Val 10…30Vdc cable5 m
$0.00USD
3840 in stock
Key Specifications
Emission:Infrared
Approvals:CE
Beam angle:± 5°
Dimensions:Ø 10mm x 46mm
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Emission | Infrared |
| Approvals | CE |
| Beam angle | ± 5° |
| Dimensions | Ø 10mm x 46mm |
| Connections | Cable 10m |
| Housing Material | Anozided aluminium |
| EMC compatibility | Conforming with EMC directive according with EN60947-5-2 |
| Operating Voltage | from UR control unit |
| Function Principle | Through-beam |
| Active Head Material | glass |
| Degree of protection | IP67 |
| Operating temperature | -20°C … +60°C |
| Nominal sensing distance | 60m |
| Interference to external light | 20000 lux |
Product Description
DGR/DN-3AEA Photoelectric sensor Receiver NPN Don D10mm clip Val=10…30Vdc cable5 m
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
