DFK-MSTB 2,5/ 2-G A0
DFK-MSTB 2,5/ 2-G A0 1726428 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
3999 in stock
Key Specifications
GTIN:4046356132480
Note:Made to Order (non-returnable)
Orderkey:1726428
Packing unit:50 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356132480 |
| Note | Made to Order (non-returnable) |
| Orderkey | 1726428 |
| Packing unit | 50 pc |
| Country of origin | DE (Germany) |
| Color (Dimensions) | green |
| Custom tariff number | 85366990 |
| Pitch (Key Commercial Data) | 5 mm |
| Width (Key Commercial Data) | 30 mm |
| (Standards and Regulations) | No hazardous substances above threshold values |
| Height (Key Commercial Data) | 20.2 mm |
| Length (Key Commercial Data) | 17.5 mm |
| Range of articles (Dimensions) | DFK-MSTB 2,5/..-G |
| Nominal current IN (Dimensions) | 12 A |
| Insulating material (Dimensions) | PA |
| Number of positions (Dimensions) | 2 |
| Dimension a (Key Commercial Data) | 5 mm |
| Rated voltage (II/2) (Dimensions) | 630 V |
| Width [ w ] (Key Commercial Data) | 30 mm |
| Height [ h ] (Key Commercial Data) | 29.5 mm |
| Length [ l ] (Key Commercial Data) | 17.5 mm |
| Rated voltage (III/2) (Dimensions) | 320 V |
| Rated voltage (III/3) (Dimensions) | 320 V |
| Weight per Piece (excluding packing) | 3.010 g |
| China RoHS (Standards and Regulations) | Environmentally friendly use period: unlimited = EFUP-e |
| Insulating material group (Dimensions) | PA |
| Rated surge voltage (II/2) (Dimensions) | 4 kV |
| Rated surge voltage (III/2) (Dimensions) | 4 kV |
| Rated surge voltage (III/3) (Dimensions) | 4 kV |
| Connection in acc. with standard (General) | EN-VDE |
| Connection in acc. with standard (Dimensions) | EN-VDE |
| Length of the solder pin (Key Commercial Data) | 9.3 mm |
| Flammability rating according to UL 94 (General) | V0 |
| Flammability rating according to UL 94 (Dimensions) | V0 |
Product Description
Feed-through housing, nominal section: 2.5 mm², color: green, nominal current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 2, number of r
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
