CTI 45MB
CTI 45MB 047B3164 DANFOSS CONTROLES INDUSTRIALES CTI 45MB Circuit breaker M/12
$0.00USD
3985 in stock
Key Specifications
EAN:5702423145072
Approval:C UL USCEEACLLC CDC TYSK
Function:Overload and short-c. protect
Net weight:0.78 Kg
Supplier Information
DANFOSS INDUSTRIAL AUTOMATION
Products: 1269
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 5702423145072 |
| Approval | C UL USCEEACLLC CDC TYSK |
| Function | Overload and short-c. protect |
| Net weight | 0.78 Kg |
| Gross weight | 0.83 Kg |
| Product name | Circuit breaker |
| Product type | CTI 45MB |
| Product Group | Contactors and motor starters |
| Packing format | Multi pack |
| Used for product | Motors |
| Product description | Circuit Breaker |
| Max. load, AC-3 [kW] | 15 kW |
| Max. trip current [A] | 416 A |
| UL approval file name | E148460 |
| Current range [A] [Max] | 32 A |
| Current range [A] [Min] | 23 A |
| Quantity per packing format | 12 pc |
| Breaking cap. Ics, 380-415 V | 50 kA |
