CS1W-BC033

CS-Series power supplies, backplanes Rack PLCExpand with up to 7 racksCS1 systems can operate on 24 VDC power supply, or on 100-240 VAC mains.For small- scale systems with mainly digital I/O a low cost, small capacity power supply can beused. For systemswith many analogI/Os and control/communication units, it may be necessary to use a larger power supply unit.PLC racks are available in several sizes, from 2 to 10 slots wide. Special backplanes are required for duplex systems. Depending on the CPU type, up to 7 expansions can beconnected to the CPU rack, giving a totalcapacity of 80 I/O units.The totallengthof the expansion cables of one system may be up to 12 m.Ordering informationPower suppliesInput rangePower consumptionOutput capacity5 VDCOutput capacity 26VDCMax. output powerExtra functionsOrder code19.2 to 28.8 VDC40 W max.6.6 A0.62 A30 W–C200HW-PD0244.3 A0.56 A28 WPower supply for dual-redundant systemCS1D-PD02455 VA max.5.3 A1.3 A40 W–C200HW-PD025Power supply for dual-redundant systemCS1D-PD02585 to 264 VAC50/60 Hz85 to 132 VAC,170 to 264 VAC,50/60 Hz120VA max. 4.6A 0.62A 30W Maintenance status displayC200HW-PA204C–C200HW-PA204Service output 24 VDC, 0.8 A C200HW-PA204S Run status output (SPST relay) C200HW-PA204R180VA max.9.0 A1.3 A45 WRun status output (SPST relay)C200HW-PA209R150VA max.7.0 A1.3 A35 W Power supply for dual-redundantsystemCS1D-PA207RBackplanesTypeSlotsExpansion connectorWidth Special functions Order codeCPU backplane 2No200 mm–CS1W-BC023CPU backplane 3Yes 260 mm–CS1W-BC033CPU backplane 5Yes 330 mm–CS1W-BC053CPU backplane 8Yes 435 mm–CS1W-BC083CPU backplane 10Yes505 mm–CS1W-BC103Expansion backplane 3Yes 260 mm–CS1W-BI033Expansion backplane 5Yes 330 mm–CS1W-BI053Expansion backplane 8Yes 435 mm–CS1W-BI083Expansion backplane 10Yes505 mm–CS1W-BI103CPU backplane 5Yes 505 mmFor DuplexCPU + Power suppliesCS1D-BC052CPU backplane 8Yes 505 mmFor Duplex Power supplies CS1D-BC082S Expansion backplane 9Yes 505 mmFor Duplex Power supplies CS1D-BI092AccessoriesTypeRemarks Order codeI/O Expansion cable to connect 0.3 m CS1W-CN313CS1 CPU backplane orExpansion backplane to nextExpansion backplane.0.7 m CS1W-CN7132.0 m CS1W-CN2233.0 m CS1W-CN3235.0 m CS1W-CN52310.0 m CS1W-CN13312.0 m CS1W-CN133-B238
